Home > Products > LCD video walls > Front push pop out wall mounted display systems lcd video wall
Front push pop out wall mounted display systems lcd video wall
- Shenzhen Hongkong
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Popular interactive flexible led screens 5.3mm bezel Samsung seamless lcd video wall
-
Easy maintenance flexible led video display video wall
-
2x1 55 inch trade show display wall
-
All size available 2x2 video wall cheap samsung video wall outdoor lcd video wall
-
55 inch digital board advertising, video wall with original Samsung lcd panel
-
3x4 42" 22mm LCD Video Wall for exhibition expo show
Product Details
Place of Origin | Guangdong, China | Brand Name | DDW | |
Model Number | DDW-LW5501 | Type | TFT | |
Application | Other, Indoor, wall mount or standing mount | Panel Size | 55 inch | |
Max Resolution | 1920*1080 | Viewing Angle | 178/178 | |
Pixel Pitch | 0.63(H)*0.63(V) | Color | 16.7M | |
Contrast Ratio | 4000:1 | Brightness | 500cd/m2 | |
Response Time | 5ms | Input Voltage | 220V |
Product Description
Front push pop out wall mounted display systems lcd video wall
55" Samsung original DID screen
LED backlight,500nits brightness
FHD 1920*1080 resolution
HDMI DVI VGA AV BNC multiple signal sources
Model No.: DDW-LW5501
55 inch lcd video wall features:
1,Original 55inch Samsung Industrial gradelcd video wall screen,16:9 LG a-Si TFT-LCD
2,LED backlight,500nits high brightness
3,HD physical resolution 1920*1080
4,Only 5.3mm Ultra narrow bezel.high quality ,Practical ,good vision effect.
5,Signal interface rich --- RS232, HDMI,DVI,VGA,Y Pb Pr ,AV
6,HD video wall unit--- High brightness,high contrast,High gamut .
7,Flexible structure design ---easy installation ,extensible,arbitrary combination
8,Stable performance,suitable working for a long ti
Specifications
Model No. | DDW-LW5501 |
Panel Specifications | |
LCD Technology | Samsung a-Si TFT-LCD |
Active Screen Diagonal | 55" (1397mm) |
Pixel Pitch(WxH) | 0.630x0.630mm |
Active Display Area(WxH) | 1209.6x680.4mm |
Panel Dimension(WxHxD) | 1215.3x686.1x64mm |
Total Bezel Width | 5.3mm | 0.208” |
Aspect Ratio | 16:9 |
Physical Resolution | 1920x1080 |
Backight System | WLED |
Luminance(nits) | 700cd/sqm |
Contrast | 3500:1 (typ.) |
Viewing Angle | H 178°|V 178° |
Display Colors | 8Bit,16.7M |
Refresh Rate | 60Hz |
Response Time | <=6ms |
Life(hrs) | >60,000(hrs) |
MTBF | > 100,000h |
Surface | Anti-glare |
Standby Power Consumption | <3W |
Maximum Power Consumption | <=250W |
Power Supply | AC100~240V 50/60 HZ |
Cooling | Low noise fans |
Heat Dissipation | 819 BTU/h (max) |
Working Time Capacity | 7x24x365hours |
Application Area | Indoor/Semi Outdoor/Outdoor |
Working Temperature | 0°C~50°C |
Working Humidity | 85% non-condensing |
Storage Temperature | -20-60°C | -4-149°F |
Storage Humidity | 85% non-condensing |
Processor | |
DVI-I DUAL LINK | 1 |
HDMI | 1 |
VGA | 1 |
CVBS IN | 1 |
CVBS OUT | 1 |
RS232 IN | 1 |
RS232 OUT | 1 |
ISP IN | 1 |
IR IN | 1 |
CODING BUTTON | 1 |
AC IN | AC100-240V |
Color System Support | PAL/NTSC/SECAM |
Control Type | IR Remote &Software Control |
Menu Language | English/Chinese(Multiple Language can be customized) |
FAQ
1. Q: Are you a manufacturer or trading company?
A:We are a manufacturer who has been specializing in producing LCD display for years.
2. Q: How does your factory do regarding quality control?
A:Quality is priority.DDW people always attach great importance to quality controlling from the
very beginning to the very end. We focus on every detail ,Our factory has gained ISO9001, ISO14001, CE, RoHS authentication.
3. Q: What is your after-sale service?
A: We offer 100% guarantee on our product .
4. Q: What is your MOQ?
A: Any quantity is acceptable for your order. And the price is negotiable for large quantity.
5. Q: When will you make the delivery?
A: We can make the delivery within 3-15 working days according to the size and quantities
of your order.
6.Q:what brand of screen are you using?
A:we are using Samsung,LG,AUO and CHIMEI screen.
7.Q: Do you have your own enclosure factory?
A:Yes we do have our own enclosure factory,and we have the best structural Engineer,we hope to provide you with best screen and shape,so OEM is also welcome.
8.Q:if you are not online,how can i get contact with you?
A:if i am not online,please kindly check the following contact information,you can send me email,you can call me or skype me,i will reply you ASAP.
Any problem,please feel free to contact with us.
