DDW 46inch 5.3mm Ultra narrow bezel Samsung LED Video Wall 1920x1080 resolution 500nits brightness
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | DDW | |
| Model Number | DDW-LW460HN09 | Type | TFT | |
| Application | Indoor | Panel Size | 46inch | |
| Max Resolution | 1920x1080 | Viewing Angle | 178x178 | |
| Pixel Pitch | 0.53025x0.53025mm | Color | 8Bit,16.7M | |
| Contrast Ratio | 3500:1 | Brightness | 500nits | |
| Response Time | 5ms | Input Voltage | 220W |
Product Description
Samsung video wall
46",5.3mm Ultra narrow bezel
1920x1080 resolution
LED backlight 800nits brightness
100% New Samsung panel
Samsung 5.3mm Ultra narrow bezel LCD Video Wall
Origianl Samsung DID
5.3mm ultra narrow bezel video wall screen
The world first &Best seller Videowall screen!!
Most cost-effective lcd videowall screen in the world
Model No.:DDW-LW460HN09
46" LED Video Wall features:
2,500nits brightness,3500:1 contrast
3,FHD physical resolution 1920x1080
4,Only 5.3mm Ultra narrow bezel.high quality ,Practical ,good vision effect.
5,Signal interface rich --- RS232, HDMI,DVI,VGA,Y Pb Pr,AV
6,FHD video wall unit--- High brightness,high contrast,High gamut
7,Flexible structure design --- easy installation ,extensible,arbitrary combination
8,Stable performance,suitable working for a long time
46" Samsung LED video wall is one of Samsung most popular Lcd video wall panels which has 5.3mm ultra narrow bezel,HD 1920x1080 resolution,and 500nits brightness,it's one of first Samsung general videowall panels in the world. Samsung lcd videowall can be used in below fields: Conference and meeting rooms, office building, lobbies, Security Monitoring Center, Surveillance and Retail Center, Restaurant and hotel, Retail Shopping Mall Advertising and information Displays, Public Installations, Exhibition and show center, Live show,Rental and advertising Center,Museums,Church,Transportation and Mass Info Display systems.
Specifications
| Samsung video wall Panel Specifications | |
| LCD Technology | SAMSUNG DID LCD |
| Active Screen Diagonal | 46" 16:9 |
| Bezel Width | Total: 5.3mm |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920x1080 |
| Backight System | LED |
| Luminance(nits) | 500cd/sqm |
| Contrast | 3500:1 |
| Viewing Angle | H 178°|V 178° |
| Pixel Pitch(WxH) | 0.53025x0.53025mm |
| Active Display Area(WxH) | 1039.8675×584.64mm |
| Panel Dimension(WxHxD) | 1023.98x578.57x49.5mm |
| White Point | 10,000 K |
| Display Colors | 8Bit,16.7M |
| Refresh Rate | 60Hz |
| Response Time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| MTBF | > 100,000 h |
| Surface | Anti-glare |
| Standby Power Consumption | <3W |
| Maximum Power Consumption | lower than 220W |
| Power Supply | AC100~240V 50/60Hz |
| Cooling | Low noise fans |
| Heat Dissipation | 819 BTU/h (max) |
| Working Time Capacity | 7x24x365hours |
| Application Area | Indoor/Semi Outdoor |
| Working Temperature | 0°C~50°C |
| Working Humidity | 0.85 |
| Storage Temperature | -20-60°C | -4-140°F |
| Storage Humidity | 85% non-condensing |
| Daisy chain videowall controller specifications | |
| DVI-I DUAL LINK | 1 |
| HDMI | 1 |
| VGA | 1 |
| CVBS IN | 1 |
| CVBS OUT | 1 |
| RS232 IN | 1 |
| RS232 OUT | 2 |
| ISP IN | 1 |
| IR IN | 1 |
| CODING BUTTON | 1 |
| AC IN | AC100-240V |
| Color System Support | PAL/NTSC/SECAM |
| Control Type | IR Remote &Software Control |
| Menu Language | English/Chinese(Multiple Language can be customized) |
| Vertical/Horizontal Display | Support |
| Combine Display | Support combine any horizental &vertical numbers of screens and show display |
| Support combine all screens together to show 1image | |
| Solid Display | Support each screen input with separate signal |
| PIP/Zoom/Roaming | Support open one window for each screen, each window can be zoomed &roaming internal freely |
| Multiple Interfaces | Support DVI,HDMI,VGA,AV &multiple signal inputs |
| Rich Resolution | Support 1080P,1080I,720P,480P &multiple resolution inputs |
| Dimension(WxHxD) | 318.4x332x56mm |
