HEPA Fan Filter Unit Ceiling Fan Filter Unit FFU
- Shenzhen
- T/T Credit Card
You May Like
Product Details
| Condition | New | Efficiency | H13 | |
| Construction | Box Filter | Filtration Grade | Hepa Filter | |
| Medium Material | Fiberglass | Porosity | 0.3um | |
| Place of Origin | Guangdong, China | Brand Name | zhisheng | |
| Model Number | ZS-FFU610 | Dimension(L*W*H) | 610x610x240mm | |
| Weight | 23kg | Certification | ISO 9001 | |
| Warranty | one year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Ceiling fan filter unit FFU1)Low vibration and noise
2)Air velocity:0.35-0.6m/s
3)Efficiency:H13
4)Material:stee
Clean room fan filter unit, FFU, HEPA filer unit
ceiling fan filter unit FFU
ISO9001 Certification
Feature:
1 The material of FFU is stainless steel, galvanized aluminum sheet or cold rolled steel, which is beautiful and prevent to rust
2 Efficiency:H13 filtering 0.3um
3 Air velocity: 0.35-0.6m/s
4 Noise:Less than 53dBA
5. Voltage:AC220V/50Hz/1Ph
Usage:
FFU can be connected for modularized application enables it to be widely applied to clean room, clean bench, clean production line, assembled clean room or local class 100 clean booth.
Optional accessory:
- Material: Cold rolled steel plated with powder, stainless steel or Galvanized Aluminum sheet
- Round duct interface or Square Duct interface
- HEPA filter or ULPA filter
- Pre filter
- Common fan or EBM fan
- Remote control
Standard size and specification:
Item Model | ZS-FFU610 | ZS-FFU915 | ZS-FFU1170 | ZS-FFU1220 | |
Size for cabinet(mm) | 610x610x240 | 915x610x240 | 1170x570x240 | 1220x610x240 | |
Material | Cold Rolled steel with powder coated/aluminum coated zinc plate/SUS#201 or 304 | ||||
Air flow(m3/h) | 600 | 900 | 1080 | 1200 | |
Air velocity(Tested under filter 300mm) | 0.35-0.6 m/s | ||||
ESP | 80-120pa | ||||
Hepa filter | Size(mm) | 610x610x69 | 915x610x69 | 1170x570x69 | 1220x610x69 |
Frame | Aluminum profile | ||||
Media | Fiberglass | ||||
Efficiency | H13 @0.3um | ||||
Pressure Drop | ≤220pa | ||||
Fan(motor) | Power | AC 220V/50Hz;AC110V/60Hz | |||
Noise(dB) | 52 | 52 | 52 | 53 | |
Optional | Control panel, Remote control, Pre filter, Pressure gauge | ||||
Weight(KG) | 22 | 24 | 28 | 32 | |
One-year guarantee
