industry microwave oven/ rubber microwave vulcanization system/hot air tunnel

Specifications

Hot air vulcanizing machine

1.CE&SGS&ISO certificated.

2.Low noise and hingh efficience.

Packaging&Delivery

Packaging details:Standard export wooden packaging 20G/40G container or according to your requirment.

Delivery details:Within 30days after receiving the deposit.

                              industry microwave oven/ rubber microwave                                vulcanization system/hot air tunnel

1.Description

 The function of this equipment is to utilize the high temperature hot air to vulcanize rubber product and then get the required performance.Different product may require the different temperature for vulcanization.The temperature can be set from 0 to 290.The equipment is easy to oprate and maintain.

2.Features

1) Specific pressure required per cm (or per inh) on product or platen decides the tonnage of the pressure.

2)Heating media(steam or electrical) curing temperature,curing time sequence to decide the method of heating,circulatory operation of the press.

3)Therefore,the selection of most appropriate press is utmost important and you can get free from SANT Engg which can make Sant Hydraulic Presses the "Zero Eorro" Presses.

3.Main parameter(18-meter hot air curing machine)

• Slot temperature:The maximum temperature is 280 degree.
• Conveyor speed:0-28.5m/min.
• Mean of conveyor:Belt conveyor.
• Product channel port(effective size):250mm(H)*120mm(W)
• Internal slot material:stainless steel plate SUS430 t1.5mm
• High teperature draught fan:1.1W ma*38m³/min(50Hz)
• The heater:electric heating 48KW,automatic control to prevent overheating.
• Width of conveyor:200mm
• Tension device:equiped with congveyor brlken alarm indicator
• Main power sorce sepecification:three phase four wire system
• Control circuit:AC220,using neutral wire
• Teperature controlling uses three components(the circuit breaker,the contactor,the thermal relay)
• The internal teperature controlling with two thermolators(control the temeprature of inner slot ) ;the inner of heating slot with one thermolator(control to prevent the temperature overheating)

 4.Our other equipments show

 5.Our service

1)Two years warranty.

2)24-hour technical support.

3)Offer lifetime service and spare parts.

4)Offer free charge of  technique training.

6.Company information

Qingdao Bojia Machinery Manufacturing Co.,Ltd  is one professional machinery manufacturer.     Our company have one good and high quality design and manufacturing technology development group,often communicate with the customers and technology authority departments of rubber industry,constantly to improve and update our products which can meet the requirements of customers:Our company guarantee to provide you excellent pre-market sale and after sale service,timely technology information consulting,accessories and consumable parts supply etc,also can design and manufacture various non-standard products according to users requirements.

Our main products are:Conveying belt molding machine series:Batch off cooling machine series:Cushion cloth renovating machine series:open mixing mill series:Vulcanizing press series:Rubber cutting machine series:Rubber slitting machine series:Logitudinal cutting machine series:Conveyor belt machine series:Other rubber machines:Design and manufacturing of automatic production line.

 Bojia machinery company always pursue”quality first,customer first”principle to offer high-quality products and excellent service,welcome new and old customers to visit our company.
