XQL Series rubber cutting machine/Single pole rubber cutting machine
- Qingdao port
- T/T
You May Like
-
Foam Rubber cutting machine/ foam rubber cutter with superior quality
-
Rubber gasket cutting machine/rubber gasket cutter with superior quality
-
Rubber band cutting machine/rubber band cutter with superior quality
-
Rubber tube cutting machine/rubber tube cutter with superior quality
-
Rubber hose cutting machine/rubber hose cutter with superior quality
-
Rubber cutting machine/rubber cutter for slipper factory
Product Details
| Condition | New | Type | Rubber Cutting Machine | |
| Place of Origin | Shandong, China | Brand Name | BOJIA | |
| Model Number | XQL | Voltage | 380V | |
| Power(W) | 4-15w | Dimension(L*W*H) | 500*400*500mm to 3500*3200*2800mm | |
| Certification | CE ISO SGS | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
1. The application
Rubber cutting machine is one of the rubber factory for processing equipment, the application of rubber cutting machine is put natural rubber or synthetic rubber cut into small blocks, makes it conform to the requirements of the use.
2. The Feature
The characteristic of XQL single-pole cutting rubber m achine possess compact structure ,convenient operation ,Less wear parts,Easy maintenance, etc. ,is one of thenecessary raw materials for rubber processing equipment.
3. .Main technical parameter
The model,Technical parameters | XQL-80 | XQL-125 | XQL-160 | XQL-240 | XQL-400D | XQL-50W |
The width of the rubber cutting knife(mm) | 660 | 760mm | 860 | 860 | 860(800*450 Plastic piece ) | 660 |
The stroke of rubber cutting knife (mm) | 660 | 660 | 680 | 660 | 660 | 300 |
The number of rubber cutting knife | 1 | 1 | 1 | 2 | 2cross2longitudinal | 1 |
Oil cylinderpressure(KN) | 80 | 125 | 160 | 240 | 400 | 50 |
The time of rubber cutting stroke(S) | 14-18 | 16-18 | 14-18 | 16-20 | 16-20 | 8-10 |
The motor power(KW) | 5.5 | 5.5 | 7.5 | 11 | 15. | 4 |
Outside size(equipment installed size)(length and width and highth) | 1800*500*2150 | 1800*500 *2150 | 2840*500 *3050 | 2000x700 x2400 | 2000x700 x2400 | 1600*1000* 1300(The highth of workbench 820mm) |
Price | 2930USD | 3250USD | 5200USD | 6170USD | 6830USD | 4880USD |
The note |
|
|
| Adhesive piece fall off | Adhesive piece fall off | Horizontal type |
4.Our advantages
* We can according your require to design some non-standard special equipment .
*We have our own factory and you can visit our factory at any time.
*Our quotes are vrey objective and have no price difference.
If you have any questions,please contact me and welcome to visit our factory.
Telephone:185 6191 1597;
Skype:live:alice_3407
