7GX-6.8C MIHENG Boat Motor 9 hp

FOB Price

Negotiable / Carton

1 Carton(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Direct Injection, Energy Efficient

Owner of 7 national-level IPR .

duct:

2.DEMO FIGURE

3.Technical Specifications

MODELS		7GX-6.8C Diesel outboard engine
Engine Type		SINGLE CYLINDER, VERTICAL TYPE, FOUR STROKE, AIR COOLED, DIRECT INJECTION
Bore x Stroke (mm x mm)		86×72mm×mm
Displacement of Piston (L)		0.418L
Rated Speed of Output Shaft		3000/1500	3600/1800
Power	Max Output KW/Ps	6.3(8.6)	6.8(9.3)
	Rated Output KW/Ps	5.7(7.8)	6.3(8.6)
Direction of Output Rotation		Anticlockwise (from the output side)
Valve Clearance (mm)		0.1-0.15(cold position)
Starting Way		Recoil Start/Electric Start
Fuel		Kgf/cm2(Mpa)	220-230(21.6-22.6)
		Fuel Supply Advance Angle	200±10
		Fuel Capacity(L)	5.5
		Mark	NO.0(Summer)/ No.-10(Winter)
Engine Lubrication		Method of Lubrication	Pressure Splash Compound
		Lubrication Oil	SAE10W-30, Level CC above
		Lubrication Oil Capacity(L)	1.65L
Engine Size (LxWxH) (mm)		418×465×495
Engine Net Weight (Kg)		≤48Kg
Machinery Net Weight (Kg)		≤78/81/84Kg
Speed of Impeller		>1400r/min
Diameter of Impeller		340mm
Transmission Fluid		Middle Duty Industrial Gear Oil HL-20
Transmission Capacity		3L
Applicable Scope		3-5 Meters Ship,Maximum load 3 tons

4.Functions added

5.Product details

6.Modern workshop and new office.

7.Certificated

8.MIHENG outboard engine

9.Comparison between old and new type of outboard engines

10. Delivery

11.Made in china.
