7GX-8.2C-ACMIHENG 12hp Marine Electric Outboard Motor
Negotiable
/ Carton
1 Carton(Min. Order)
- CHONGQING
- T/T Credit Card
You May Like
-
MIHENG 20HP 7GX-15C-AC Outboard Engine 4 Stroke Electric Start(4HP-20HP)
-
4 Stroke Best Outboard Engine in China
-
4 Stroke 4 HP Gasoline Fuel Type Outboard Engine Hot Sale
-
Small Electric Fishing Outboard Engine With CE Certification
-
CE Approved Electric Small Boat Engine for Fishing
-
4 Stroke 4 HP Small Outboard Engine for Hot Sale
Product Details
| Condition | New | Engine | 4 Stroke | |
| Fuel Type | Diesel | Cylinders | 1 | |
| Engine Position | Outboard |
Product Description
Direct Injection, Energy Efficient
Owner of 7 national-level IPR .
duct:
2.DEMO FIGURE
3.Technical Specifications
| MODELS | 7GX-8.2C-AC Diesel outboard engine | ||
| Engine Type | SINGLE CYLINDER, VERTICAL TYPE, FOUR STROKE, AIR COOLED, DIRECT INJECTION | ||
| Bore x Stroke (mm x mm) | 88×75mm×mm | ||
| Displacement of Piston (L) | 0.456L | ||
| Rated Speed of Output Shaft | 3000/1500 | 3600/1800 | |
| Power | Max Output KW/Ps | 7.5(10.2) | 8.2(11.2) |
| Rated Output KW/Ps | 7(9.5) | 7.5(10.2) | |
| Direction of Output Rotation | Anticlockwise (from the output side) | ||
| Valve Clearance (mm) | 0.1-0.15(cold position) | ||
| Starting Way | Recoil Start/Electric Start | ||
| Fuel | Kgf/cm2(Mpa) | 220-230(21.6-22.6) | |
| Fuel Supply Advance Angle | 200±10 | ||
| Fuel Capacity(L) | 5.5 | ||
| Mark | NO.0(Summer)/ No.-10(Winter) | ||
| Engine Lubrication | Method of Lubrication | Pressure Splash Compound | |
| Lubrication Oil | SAE10W-30, Level CC above | ||
| Lubrication Oil Capacity(L) | 1.65L | ||
| Engine Size (LxWxH) (mm) | 418×465×495 | ||
| Engine Net Weight (Kg) | ≤48Kg | ||
| Machinery Net Weight (Kg) | ≤84Kg | ||
| Speed of Impeller | >1400r/min | ||
| Diameter of Impeller | 380mm | ||
| Transmission Fluid | Middle Duty Industrial Gear Oil HL-20 | ||
| Transmission Capacity | 3L | ||
| Applicable Scope | 7-13 Meters Ship,Maximum load 4 tons | ||
4.Functions added
5.Product details
6.Modern workshop and new office.
7.Certificated
8.MIHENG outboard engine
9.Comparison between old and new type of outboard engines
10. Delivery
11.Made in china.
