7GX-3.1C MIHENG Motor Outboard Marine(4HP-20HP)
Negotiable
/ Carton
1 Carton(Min. Order)
- CHONGQING
- T/T Money Gram Credit Card
You May Like
-
7GX-6.8C MIHENG Boat Motor 9 hp
-
7GX-8.2C-ACMIHENG 12hp Boat Motor Outboard Made in China
-
7GX-4.4C MIHENG4 Stroke 6hp Boat Engine
-
MIHENG 20HP 7GX-15C-AC Electric Outboard Motor Boat (4HP-20HP)
-
New Condition 4 Stroke 6hp Diesel Marine Engine Sail for Fishing Boat
-
7GX-6.8C MIHENG 9hp Marine Diesel Engine With Gearbox
Product Details
| Condition | New | Engine | 4 Stroke | |
| Fuel Type | Diesel | Cylinders | 1 | |
| Engine Position | Outboard | Dimensions (L x W x H) (mm) | 332*396*420mm |
Product Description
Direct Injection, Energy Efficient
Owner of 7 national-level IPR .
duct:
2.DEMO FIGURE
3.Technical Specifications
| MODELS | 7GX-3.1 | ||
| Engine Type | SINGLE CYLINDER, VERTICAL TYPE, FOUR STROKE, AIR COOLED, DIRECT INJECTION | ||
| Bore x Stroke (mm x mm) | 70×55mm×mm | ||
| Displacement of Piston (L) | 0.211L | ||
| Rated Speed of Output Shaft | 3000/1500 | 3600/1800 | |
| Power | Max Output KW/Ps | 2.8(3.8) | 3.1(4.2) |
| Rated Output KW/Ps | 2.5(3.4) | 2.8(3.8) | |
| Direction of Output Rotation | Anticlockwise (from the output side) | ||
| Valve Clearance (mm) | 0.1-0.15(cold position) | ||
| Starting Way | Recoil Start/Electric Start | ||
| Fuel | Kgf/cm2(Mpa) | 220-230(21.6-22.6) | |
| Fuel Supply Advance Angle | 200±10 | ||
| Fuel Capacity(L) | 2.5 | ||
| Mark | NO.0(Summer)/ No.-10(Winter) | ||
| Engine Lubrication | Method of Lubrication | Pressure Splash Compound | |
| Lubrication Oil | SAE10W-30, Level CC above | ||
| Lubrication Oil Capacity(L) | 1.65L | ||
| Engine Size (LxWxH) (mm) | 332×396×420 | ||
| Engine Net Weight (Kg) | ≤25Kg | ||
| Machinery Net Weight (Kg) | ≤55/58/61Kg | ||
| Speed of Impeller | >1400r/min | ||
| Diameter of Impeller | 240mm | ||
| Transmission Fluid | Middle Duty Industrial Gear Oil HL-20 | ||
| Transmission Capacity | 3L | ||
| Applicable Scope | 4-7Meters Ship,Maximum load 1 tons | ||
4.Functions added
5.Product details
6.Modern workshop and new office.
7.Certificated
8.MIHENG outboard engine
9.Comparison between old and new type of outboard engines
10. Delivery
11.Made in china.
