Pine Nut Processing /color Sorter
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai
- Credit Card
You May Like
Product Details
| Place of Origin | Anhui, China | Brand Name | Angelon |
Product Description
Specifications
1.Track-type CCD color sorter2.ISO9001.CE, ETL, UL
3.High-resolution CCD image sensor
4.Computer control
- Adopt higher-resolution chromatic CCD sensor, separate red, green, blue, gray and many different colors respectively.
- Belt type, avoid the jumping in traditional chute-type color sorter, and increase the output.
- With world-class optics, high-definition within 0.07 mm2, could identify subtle color and minimal defects.
- Unique double layer belt-type design, increase the accuracy and could finish all the processing procedure at the same time.
- High-speed parallel data processing chip, real-time and efficient image acquisition and processing system, greatly improving the efficiency of color sorters.
- Convenient computer operating system could save many different sorting mode for clients in order to suit different materials.
Product features:
- High-Definition and high-sensitivity chromatic CCD image sensor, together with industrial wide-angle lens for accurate recognition;
- Adopt the international first-class optical lens; the articulation up within 0.07 mm2 can recognise a subtle chromatism and tiny flaws.
- By using high-speed parallel data processing chip, real-time efficient image acquisition and processing system, greatly improving the color separator working efficiency.High quality image processing algorithm:
- Adopt international advanced image processing technology, can effectively identify small to 0.1 mm of tiny impurities, color choose higher accuracy, color choose than lower brought out.
- Convenient computer operating system, could save many different sorting mode for clients in order to suit different materials.
- Unique LED lighting system, Equipped with LED light source, and to ensure the high-definition image quality, can meet 1000 kinds of color separation, identify color changes.
- Fan self-adaptive working temperature, ensure color separator in the high temperature environment also can work normally.
- The incomparable eliminate accuracy, more perfectly sorting out finished with a defective; high resolution, big material nozzle; High frequency, long durability and long service life.
- Easy for clients to install in factory. Unique double layer belt-type design could finish all the processing procedure at one time, and only need one elevator.
Type | AL1K2C8-128,256 | |
Channels | 128, 256 | |
Output(t/h) | 2-4 | |
Sorting accuracy (%) | >99.98 | |
Optimized carryover(bad :good) | >9/1 | |
Voltage (V) | ~220(50Hz) | |
Power of main machine (kW) | 2.0 | |
Air Pressure (MPa) | 0.6~0.8 | |
Dimension(L*W*H)(mm) | 2730*1820*1580 | |
Weight (kg) | 950 |
