Air Cylinder SCJ Series Standard Cylinder
US$ 1 - 100
/ Piece
50 Pieces(Min. Order)
- Ningbo/Shanghai
- T/T
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Piston Cylinder | |
| Power | Pneumatic | Body Material | Aluminum | |
| Maximum Stroke | 1500mm | Shaft Diameter | 32~400mm | |
| Place of Origin | Zhejiang, China | Model Number | SCJ 80*250-25 | |
| Brand Name | WEHOPE |
Product Description
Specifications
1. Many years experiences.2. High quality , favorable price .
3. Fast delivery , best service .
Product Description
| Production characteristics | ||
| Free lubrication | ||
| Because of oil bearing, the piston pole needn't lubricating. | ||
| Buffering | ||
| Besides fixed buffer, the cylinder terminal has adjustable buffer, so that the cylinder enters into stably without impact during commutating. | ||
| High temperature resistance | ||
| Because of sealing material of high temperature resistance, the cylinder can work normally at 150 (user can order it from us) | ||
| Many kinds of installation accessories can be selected by user. | ||
| Magnetic property | ||
| The cylinder piston is equipped with a permanent magnet that can trigger the magnetic switch of the cylinder to detect the moving position of cylinder. | ||
| Specification | |||||||||||||||
| Inner diameter | 32 | 40 | 50 | 63 | 80 | 100 | 125 | 160 | 200 | 250 | 320 | ||||
| Action type | Double-action type | ||||||||||||||
| Work medium | Air | ||||||||||||||
| Fixed type | Basic type FA FB CA CB LB TC TC-M | ||||||||||||||
| Applicable pressure 2 Kgf/cm | 1~9.0 | ||||||||||||||
| 2 Guaratee pressure with stand Kgf/cm | 13.5 | ||||||||||||||
| Applicable Temperature | -5~70 | ||||||||||||||
| Applicable speed mm/s | 50~800 | ||||||||||||||
| Buffer type | Adjustable buffer | ||||||||||||||
| Buffer travel mm | 24 | 32 | |||||||||||||
| Pipe size | PT1/8 | PT1/4 | PT1/4 | PT3/8 | PT3/8 | PT1/2 | PT1/2 | PT1/2 | PT3/4 | PT3/4 | G1 | ||||
| Travel | ||||
| (mm)Inner diameter | Standard travel | Max travel | Allowable travel | |
| 32 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 | 1000 | 2000 | |
| 40 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 | 1200 | 2000 | |
| 50 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1200 | 2000 | |
| 63 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 2000 | |
| 80 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 2000 | |
| 100 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 2000 | |
| 125 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 2000 | |
| 160 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 2000 | |
| 200 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 2000 | |
| 250 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 2000 | |
| 320 | 25 50 75 80 100 125 150 175 200 250 300 350 400 450 500 600 700 800 900 1000 | 1500 | 2000 | |
| Ordering Code | |||||
| SCJ - 8 * 250 - 25 S - LB | |||||
| SUJ - 4 * 100 - 25 - FA | |||||
| SCD: Standard double-action type Pull-pole type | |||||
| SUD: Standard double-action type No pull-pole type | |||||
