2012 Asia Popular Twin Shaft JS500 Concrete Mixer
- Shanghai/Qingdao or others ports of Cina
- T/T Credit Card
You May Like
-
Electronic Portable Twin Shaft JS500 Concrete Mixer
-
JS2000 Electronic Concrete Mixer With Twin Shaft
-
JS Series Small Portable Concrete Mixer JS500 With Twin Shaft
-
Twin Saft Small Concrete Mixer JS500
-
Twin Saft High Quality Small Concrete Mixer JS500 for Sale
-
Double Horizontal Axles High Quality Forced Concrete Mixer JS1000
Product Details
| Condition | Used | Place of Origin | Henan, China | |
| Brand Name | Bizoe | Model Number | JS500 | |
| Motor Power | 750W | Mixing Power | 18.5kw | |
| Charging Capacity | 800L | Reclaiming capacity | 500L | |
| Speed of Mixing Drum | 35r/min | Water Supply Mode | Water pump | |
| Working Cycle Period | 60s | Discharge Way | auto | |
| Outline Dimension | 4461x3050x5225mm |
Product Description
Specifications
1:very popular one twin shaft cncrete mixer2:CE&ISO9000 certificate
3:best price
Products pics:
Products introduction:
DASION JS500 twin-shaft concrete mixer has double horizontal mixing axles, which can produce dry-hard concrete, half-dry concrete, plasticity concrete, light-aggregate concrete and variety of mortar. They are applicable to the normal construction projects, road/bridge site, or small or medium size concrete component factories. JS series twin-shaft concrete mixer adopt new type of aggregate feeding device and mixing blades connection style, that improves the mixer stability, mixing quality, mixing speed, productivity, and keep long-term service life. JS series twin-shaft concrete mixer can be working independently, which also be the best choice for old Concrete Batching Plant replacement.
Technical features of JS twin-shaft concrete mixer:
1. adopt 3-phases electric motor;
2. Gear reducer for force transmission;
3. Self-lock motors for aggregate bucket lifting;
4. Centrifugal pump for water feeding or flushing
JS 500 Concrete Mixer
Main parameters and description of JS500 Twin-shaft Concrete Mixer
Model | JS 500 |
Capacity | 25m3/h |
Discharging volume | 500L |
Charging volume | 800L |
Max. aggregate size | 80/60mm |
Mixing blades Rotating-speed & Qty. | 35r/min, 2x7pcs |
Mixing motor Model & Power | Y180L-4, 18.5kw |
Hoisting motor Model & Power | YEZ132S-4-B5, 5.5kw |
Water pump Model & Power | 50DWB20-8A, 0.75kw |
Bucket lifting speed | 18m/min |
Dimension | 4461x3050x5225mm |
Total weight | 4000kg |
Discharging height | 1500mm |
Item parameter model | JS500 | JS750 | JS1000 | JS1500 | |
Discharge capacity(L) | 500 | 750 | 1000 | 1500 | |
Feeding capacity(L) | 800 | 1200 | 1600 | 2400 | |
Max production rate | ≥25m³/h | ≥37.5m³/h | ≥50m³/h | ≥75m³/h | |
Maximum aggregate sizes(pebble/gravel) | 80mm/60mm | 80mm/60mm | 80mm/60mm | 80mm/60mm | |
Working circle | 60s | 60s | 60s | 60s | |
Mixing blade | rational speed | 35r/min | 31r/min | 25.5r/min | 25.5r/min |
| quantity | 2×7 | 2×7 | 2×8 | 2×10 |
Mixing motor | Type | Y180M-4 | Y200L-4 | Y225S-4 | Y225M-4 |
| power(kw) | 18.5 | 30 | 37 | 45 |
Hoist motor | Type | YEZ1325-4-B5 | YEZ132M-4-B5 | YEZ160S-4 | YEZ180L-4 |
| power(kw) | 5.5 | 7.5 | 11 | 18.5 |
Pump motor | Type | 50DWB20-8A | 65DWB35-8A | KQW65-1001 | KQW65-1001 |
| power(kw) | 0.75 | 1.1 | 3 | 3 |
Size | transporting status(mm) | 3050*2300*2680 | 3650*2600*2890 | 4640*2250*2250 | 5068*2250*2440 |
| working status(mm) | 4461*3050*5225 | 4951*3650*6225 | 8765*3436*9540 | 9645*9436*9700 |
Total weight(kg) | 4000 | 5500 | 8700 | 11130 | |
Discharge height(mm) | 1500 | 1600 | 2700/3800 | 3800 | |
Speed of Hopper lifting (m/min) | 18 | 18 | 21.9 | 23 | |
