Outdoor HD SDI IR Speed Dome Camera, 2.0MP 1080P PTZ Camera

Specifications

HD-SDI Outdoor IR Speed Dome Camera   2.0MP 1080P WDR,20X Optical zoom,12X Digital zoom, ICR

Housing Features:

* Using aluminum alloy spherical shell design, part compact enclosures with high strength, good thermal property .

* Using the primary system, cameras, infrared lamp module design of an isolation shell protection, waterproof performance, high reliability, camera positions internal nitrogen filled.

 * Using the latest third-generation infrared array (LED Array) light source. Infrared lamp high brightness, exposure, distance, light distribution, long service life  .

* Infrared lamp brightness control function. Infra-red control lamp brightness control (indoor models), automation (outdoor models) and manually controlling the three modes, according to the monitoring target distances near and far, low, medium and high exposure to infrared lamp brightness to meet different range target infrared light irradiation when the monitor brightness requirements, most night vision distance up to 120 feet away, 6-array CPV LED

*Pan/Tilt with precision stepping motor driving, smooth, rapid and sensitive response, high positioning accuracy.                                                             *Pan/Tilt speed is automatically adjusted: pan/tilt speed with zoom lens depth increases its speed gradually in proportion to lower

* PTZ support multiple communication protocols and baud rate, high system compatibility                                                                          * EEPROM data storage, user data is not lost when power                                                                        *Pan360°continuously, Tilt 90°rotation, auto flip, humanize focus and speed proportion

*128 presets(tiles can be set),1 tour;8 programmable zones(titles can be set); 4pattern, each record time is not less than 180s;

*1scan, support scan repeatedly between right and left limit at an appointed speed;

*Support Scan, Tour, Pattern, Parking Time, Privacy Protection;

*IP 66 whole day defend cover.

CAMERA FEATURES:

Outdoor HD SDI IR Speed Dome Camera, 2.0MP 1080P PTZ Camera

Auto, Sodium Vapor Lamp Fix/Auto, One-push, Manual)

• Picture effects (E-Flip, Nega Art, Black & White, Mirror Image, Colour Enhancement)

• Picture freeze

• Temperature readout

• Slow AE response (Approx. 5 min.)

• Title display (20 characters per line, max. 11 lines)

• Camera mode display (English)

• Electronic shutter/slow shutter

• Spot AE

• High Resolution Mode

• IR Focus Correction Function

• 4 Presets for Gamma Control

• 4 Levels of Chrominance Suppression

• Colour reproduction adjustment

DATA SHEET:
