Fiber terminal box ODF/ wall mounted ODF

FOB Price

Negotiable / Set

2 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	tincam
Model Number	TBC-ODF-RS24, terminal box

wall mounted ODF

Features:

1) Material: cold rolled steel or aluminum

2) The body with electrostatic spraying surface, light structure and good-looking appearance

3) Optical cables can be lead in/out from upside or downside

4) 48-core adapter panels mounted in the front board are selectable with FC/SC/ST

5) Unique plastic retainer clips for optical fibers are attached, protecting the spliced fibers sufficiently

USES and features:

1.Suitable for fiber optic cable and optical communication equipment wiring connection;

2.Suitable for fiber optic cable and wiring tail fiber protective connection;

3.Adopts front structure, optical fiber expansion, convenient deployment

4.Single core cable and ribbon cable gm;

5.Welding flange desirable operating outside the box body, the construction, maintenance, simple and convenient;

6.Set up to strengthen the core fixed device, reliable grounding and protection safety;

7.Card type adapter end plate meet the FC, SC, ST fiber adapter deployment of installation.

Technical index:

Item:	Specifications:
Product Name:	Fiber optical connection box TBC-ODF-RS48
Model:	TBC-ODF-RS48
Type:	Wall mounted type
Card type adapter end plate:	FC/SC/ST
Adapter:	48 cores
Working temperature:	2-10 °C ~ + 40 °C
Ambient temperature:	- 25 °C ~ + 55 °C
Relative humidity:	< 85% (30 °C)
Atmospheric pressure:	70 kpa to 106 kpa
Return loss:	FC/PC>50Db FC/APC>60Db
With Lock:	Yes
Material:	Cold rolled steel or aluminum
Color:	Light gray
Product inlook size:	46039085
Product outlook size(mm):	49040090
Certification:	CE & RoHS
Warranty:	3 year
Supplier:	Alibaba 5th year Gold Supplier
Delivery:	Timely

Packaging & Shipping
