Multimode duplex LC fiber patch cables
- Shenzhen China
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Tincam | |
| Model Number | TBC-MU patch cord | Number of Conductors | 2 |
Product Description
Multimode duplex LC fiber patch cables
Detailed Product Description
We offers single mode and multimode FC single mode patch cord ,SC-LC,SC-ST,SC-FC,SC-MU,SC-MT-RJ,SC-E2000,etc types custom design SC fiber optic patch cord. assemblies,9/125(G.657A,G.657B,G.655,G.652D),50/125,62.5/125,SM,MM,simplex,Duplex.Any other specification is available on request.
Applications:
CATV,LAN,MAN,WAN,FTTH,FTTB;
Fiber-optical communications system;
Test & Measurement,Industry,Medical.
Features:
Good interoperability;
Low insertion loss;
Fiber diameter: Φ0.9, Φ2.0, Φ3.0;
Ceramic ferrules,PC,UPC and APC polishing;
PVC or LSZH jacket cable.
Specifications:
Patch cord Connector | SC/PC(SM) | SC/UPC(SM) | SC/APC(SM) | SC/PC(SM) |
Return Loss (dB) | ≥45 | ≥50 | ≥60 | ≥35 |
Insertion Loss (dB) | ≤0.2 | |||
Repeatability (dB) | ≤0.1 | |||
Durability(1/Matings) | ≥1000 | |||
Operation Temperature | -40~+80 | |||
Tensile Strength (N) | ≥90 (Φ3.0), ≥70 (Φ2.0), Φ0.9 | |||
Order information:
SC/ PC – SC/ PC/ SM/ 2C/ 3.0 – 3M
1 2 1 2 3 4 5 6
1.Connector type:FC,SC,LC,ST,MTRJ,MU,E2000,MPO,DIN,D4,SMA;
2.Ferrule End-face:PC,APC;
3.Fiber Type:Single-mode(SM:9/125um),Multimode(MM:50/125um or 62.5/125um);
4.Cable Diameter:3.0mm,2.0mm,0.9mm;
5.Cable Diameter:3.0mm,2.0mm,0.9mm;
6.Length:1,2,3 meter or sustomized length;
7.Cable type:PVC,LSZH,OM3,OFNR,OFNP,Plenum
Dimension Structure:
Pictures.
