Home > Products > Fiber Optic Passisive Device > FC/PC-FC/PC 2 meter optic fiber patch cord
FC/PC-FC/PC 2 meter optic fiber patch cord
- Shenzhen China
- Credit Card PayPal
You May Like
-
9\/125um sc/pc 3.0mm Patch Cord
-
SC/PC-SC/PC Fiber optic patch cord pigtail G652D G657A G657B 9\/125um
-
China Made Customized Fiber Optical 1x8 PLC Splitter
-
China Made Customized Fiber Optical 1x8 PLC Splitter
-
1X2 1X4 1X8 1X16 1X32 1X64 optical splitter / fiber optic splitter / plc splitter
-
Low price Supplier 1x32 optical splitter, 1x8 plc splitter
Product Details
| Place of Origin | Guangdong, China | Brand Name | Tincam | |
| Model Number | TBC-LC-FC SM 3.0 | Type | Cat 1 | |
| Number of Conductors | 1 |
Product Description
FC/PC-FC/PC 2 meter optic fiber patch cord
Detailed Product Description
ST-SC patch cord .We offers single mode and multimode FC fiber optic patch cord cable, UTP cat 5 cable, UTP cat 5.SC-LC,SC-ST,SC-FC,SC-MU,SC-MT-RJ,SC-E2000,etc types custom design SC fiber optic patch cord assemblies,9/125(G.657A,G.657B,G.655,G.652D),50/125,62.5/125,SM,MM,simplex,Duplex.Any other specification is available on request.
Applications:
CATV,LAN,MAN,WAN,FTTH,FTTB;
Fiber-optical communications system;
Test & Measurement,Industry,Medical..
Features:
Good interoperability;
Low insertion loss;
Fiber diameter: Φ0.9, Φ2.0, Φ3.0;
Ceramic ferrules,PC,UPC and APC polishing;
PVC or LSZH jacket cable.
Specifications:
Patch cord Connector | SC/PC(SM) | SC/UPC(SM) | SC/APC(SM) | SC/PC(SM) |
Return Loss (dB) | ≥45 | ≥50 | ≥60 | ≥35 |
Insertion Loss (dB) | ≤0.2 | |||
Repeatability (dB) | ≤0.1 | |||
Durability(1/Matings) | ≥1000 | |||
Operation Temperature | -40~+80 | |||
Tensile Strength (N) | ≥90 (Φ3.0), ≥70 (Φ2.0), Φ0.9 | |||
Order information:
SC/ PC – SC/ PC/ SM/ 2C/ 3.0 – 1M
1 2 1 2 3 4 5 6
1.Connector type:FC,SC,LC,ST,MTRJ,MU,E2000,MPO,DIN,D4,SMA;
2.Ferrule End-face:PC,APC;
3.Fiber Type:Single-mode(SM:9/125um),Multimode(MM:50/125um or 62.5/125um);
4.Cable Diameter:3.0mm,2.0mm,0.9mm;
5.Cable Diameter:3.0mm,2.0mm,0.9mm;
6.Length:1,2,3 meter or sustomized length;
7.Cable type:PVC,LSZH,OM3,OFNR,OFNP,Plenum
