Home > Products > RV Series Worm Gearbox > NMRV+NMRV Double Stage Worm Gear Speed Reducer With High Quality
NMRV+NMRV Double Stage Worm Gear Speed Reducer With High Quality
- Shanghai or Ningbo
- T/T
You May Like
-
China Manufacturer NMRV+NMRV Double Stage China Gear Reducer
-
NMRV+NMRV Worm Gearbox Hollow Shaft
-
China Manufacturer High Quality NMRV Mini Worm Gear Reducer
-
RV Series Aluminun Mini Worm Gear Box With High Quality
-
NRV..VS Series Worm Gear Speed Reducer With Output Flange
-
NMRV..F BL Worm Shaft Reducer RV Series Worm Gear Reduction Gearbox
Product Details
| Gearing Arrangement | Worm | Output Torque | by the Ratio | |
| Rated Power | 0.06-15kW | Input Speed | 1400rpm | |
| Output Speed | 14-280rpm | Place of Origin | Zhejiang, China | |
| Model Number | NMRV+NMRV speed reducer | Brand Name | HENGBAI |
Product Description
RV series worm gear speed reducer
Type: | NMRV+NMRV Double Stage Worm Gear Speed Reducer |
Model: | NMRV+NMRV030, 040, 050, 063, 075, 090, 110, 130 |
Ratio: | 1:25-10000 |
Color: | Blue/silver/green or on customer’s request |
Material: | Housing-aluminum with oven painting for RV030-090 speed reducer, cast iron for RV110 and 130 speed reducer |
Worm Whele-ZQAl9-4-4-2 | |
Worm Shaft- 20Cr steel.The hardness of surface is 56-62HRC with carbonized layer 0.3-0.5mm | |
Bearing: | QC |
Oil Seal: | CTY |
Packing: | Inner pack: use plastic bag and foam box, Outer pack: carton or wooden case per set or based on customer's request. |
Warranty: | 1 year |
Application: | Industrial Machine: Food Stuff, Ceramics, Chemical, Packing, Dyeing, Woodworking, Glass. |
Hangzhou Hengbai Gear Reducer Co.,Ltd. has been a specialized manufacturer in designing and
producing speed reducer for nearly 20 years. We imported advanced technology from United States,
Germany and Japan, adopted CAD design and reasonable arrangement. The Hengbai products
always receive faith from old and new customers.
Website: /
(1) With excellent quality and Reasonable price
(2) Promise to delivery on time
(3) Safe, reliable, economical and durable
(4) Stable transmission, quiet operation
(5) High heat-radiating efficiency, high carrying ability
(6) Every product must be tested before sending
Kindly, pls send the Model, Ratio, and Quantity to us, then we will give you the best price.
speed reducer, speed reducer, speed reducer, speed reducer, speed reducer, speed reducer, speed reducer, speed reducer
