Touch screen monitor/ panel
US$ 1 - 9,999
/ Set
10 Sets(Min. Order)
- Shenzhen
- T/T Credit Card
You May Like
Product Details
| Products Status | Stock | Screen Size | Other, 42" | |
| Type | Infrared | Interface Type | Serial, USB, Other, Serial, USB, HDMI,Composite video input | |
| Resolution | Other, 1920*1080 | Brand Name | User Or OEM | |
| Model Number | US-T4001WP | Place of Origin | Guangdong, China |
Product Description
Specifications
touch screen monitorHigh definition and brightness
Good in quality and moderate in price
Android system
High definition and brightness
Good in quality and moderate in price
Delivery timely
Warranty One Year
nice design lcd touch screen monitor with Android system
| Specifications | ||||||||||
| Model No. | US-T4001HC-A | |||||||||
| Panel size | 40" TFT-LCD | |||||||||
| Display area(mm)/mode | 930(W)×523.0(H) 16:9 | |||||||||
| Maximum resolution | 1920×1080 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.4845(H)×0.4845(V) | |||||||||
| Brightness (nits) | 500cd/m2 | |||||||||
| Contrast | 1400:1 | |||||||||
| Visual angle | 178°/178° | |||||||||
| Response time | 8ms | |||||||||
| Horizontal frequency | 50-70KHZ | |||||||||
| Backlight mode | LED | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Specifications for touch screen | ||||||||||
| Panel size | 26"~65" | |||||||||
| Maximum resolution | 4096*4096 | |||||||||
| Linearity error | <5MM | |||||||||
| Scanning speed | 50SCANS/S | |||||||||
| Durability | stand more than 60000000 times multi-points touch | |||||||||
| Surface hardness | 7H | |||||||||
| Transmittance | ≥98% | |||||||||
| Response time | <16MS | |||||||||
| System support | Android , WIN7/XP | |||||||||
| Input and output | ||||||||||
| SD | 1 (support 1080P, up to 32G) | |||||||||
| SATA hard disk | support | |||||||||
| Network infterface | RJ45 10/100M Network Adaptive | |||||||||
| D-15 pin RGB input | 1 | |||||||||
| USB | Support USB 2.0, support FAT,FAT32,exFAT and NTFS format | |||||||||
| LVDS interface | can drive lcd screen directly | |||||||||
| Video and audio | ||||||||||
| Video system | PAL/NTSC/SECAM | |||||||||
| Play formats | Compatible many play formats | |||||||||
| Video | H.264,MKV,WMV9,MPEG 1/2/4,HD Divx,Xvid,RM/RMVB | |||||||||
| Audio | MP3,WMA,WAV,EAAC+, MP2 dec, Vorbis(Ogg), AC3, FLAC, APE, BSAC | |||||||||
| Picture | BMP/PNG/GIF/JPEG(4088*4088) | |||||||||
| Word | TXT | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | <=280W | |||||||||
| Standby power consumption | <=3W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -10°C~60°C | |||||||||
| Working humidity | 20%~80% | |||||||||
| Storage humidity | 5%~95% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 1249.6×739.2×122.2((for reference only) | |||||||||
| Panel color/appearance | Ipad design | |||||||||
| Panel material | SPCC/Aluminum/Customized | |||||||||
| Installation | wall mount | |||||||||
| Certificate | CE/FCC/3C/RoHS | |||||||||
Package&Loading:
We provide servise:
1. Customized requirment is available , OEM&ODM are welcome.
2. Reasonable and satisfactory solutions Provided to you by our professional engineers and staffs .
3. Warranty: one year overall unit ( Non-artificial damage )
Certificate:
Office and Workshop:
Company breif introduction and products range:
ShenZhen User Special Display Technologies CO.,Ltd. As one of the leading providers of special display solution manufactor specialized in development ,production and marketing of LCD monitor 5″-82 ″Various Size. We also provide CCTV LCD monitor,Industrial LCD monitor,Broadcast LCD monitor,medical LCD monitor,Touch screen LCD monitor,Multimedia kiosk, high definition LCD display ,LCD Advertising player,Digital signage,Billboards,LCD video wall, LCD splicing,LCD display wall,video wall processor and so on. Any inquires are warmly welcome!
