42" High Definition 1080P LCD Digital Signage

FOB Price

USD $1 - $9,999 / Set

10 Sets(Min.Order)

Supply Ability 1000 Set / Sets per Month
Port shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	User Or OEM
Model Number	US-AH42WNA	Type	TFT
Application	Taxi	Panel Size	42inch
Max Resolution	1920*1080	Viewing Angle	178D
Pixel Pitch	0.4845mm	Color	16.7M
Contrast Ratio	4000:1	Brightness	450cd/m2
Response Time	6ms	Input Voltage	AC110~240V 3A 50/60Hz, 220W

Product Description

Specifications

1.1920 * 1080P resolution
2.31.5" high definition LCD
3.USB upgrade, timer
4.Flexible open frame design
5.CE, Rohs,FCC

Main Function

Key Function:

1. Open frame instruction design, which is flexible to embed into structure objects.

2. Upgrade contents of the memory card (or Built-in memory) by simply inserting an USB flash drive

3. The player starts automatically when the IR body sensor detects an approaching viewer (optional and external)

4. Timer function: the player turns on / off at the same time everyday according to your setting

Main Function:

1. Play mp4 movie, mp3 music and digital photos; Built-in 42 inch TFT LCD screen; Flexible to embed into all kinds of structure objects.

2. Play from:
--Compact Flash card (CF / SD card)

--USB flash drive
--Built-in memory

3. Upgrade contents of the memory card (or built-in memory) by simply inserting an USB flash drive, no need to take out of the memory card

4. Timer function: the player powers on / off automatically everyday at the time pre-set; It can also automatically play and non-stop replay within the pre-set time frame

5. No DVD style mechanical movement, hence more durable and suitable for long-hour advertising playing

6. IR (infrared) body sensor (external and optional): player starts automatically when the sensor detects an approaching viewer

7. Audio output (external): 2 X built-in high quality stereo speakers

Images of Various Angles:

Specifications
Model No.	US-AH42WNA
Panel size	42" LED backlight, All New A+ panel
Display area(mm)/mode	930(W)×523(H) 16:9
Maximum resolution	1920*1080 FHD
Display color	16.7M
Pixel Pitch(mm)	0.4845(H)×0.4845(V)
Brightness (nits)	500nits
Contrast	4000:1
Visual angle	178°/178°
Response time	5ms
Life(hrs)	60,000(hrs)
Input and output
LAN	RJ45
WIFI Module	Included
USB	2 ( USB2.0 interface)
SD	1 (Compatible MMC/MS)
Speaker	2×5W(9Ω)
Video
Color system	PAL/NTSC/SECAM
Remote controller	YES
OSD display( screen menu display)
Menu language	Chinese/English
Power
Power supply	AC100~240V 50 /60 HZ
Maximum power consumption	220W
Standby power consumption	2W
Temperature
Working temperature	0°C~50°C
Storage temperature	-20°C~60°C
Working humidity	85%
Storage humidity	85%
Appearance
Color/appearance	White,black,customized
Case	Metal case SPCC
Tempered glass	4mm
Installation	Wall mount/bracket
Packing size	1100mm×680mm×120mm
Gross Weight	35kg
Quality Standard	ISO9001,CCC
Detailed functions
Video format	MPEG1/MPEG2/MPEG4/DivX/ASP/WMV/AVI
Audio format	Wave/MP3/WMA/AAC
Image format	JPEG/BMP/TIFF/PNG/GIF
Image resolution	480P/720P/1080P
Landscape and Portrait mode	Support

Package:

We provide servise:

1. Customized requirment is available , OEM&ODM are welcome.

2. Reasonable and satisfactory solutions Provided to you by our professional engineers and staffs .

3. Warranty: one year overall unit ( Non-artificial damage )
