Interactive touch Totem, 19''/22''/32''/42''/46''/55''/65''/70''/82''

Specification

Model No.

US-T2201HC

Panel size

22’’ TFT-LCD

Display area(mm)/mode

496(W)×298(H) 16:9

Maximum resolution

1680x1050

Display color

16.7M

Pixel Pitch(mm)

0.282(H)×0.282(V)

Brightness (nits)

300nits

Contrast

1000:1

Visual angle

176°/176°

Response time

6ms

Horizontal frequency

50-70KHZ

Vertical frequency

56-75KHZ

Life(hrs)

60,000(hrs)

Touch Panel

Specification

IR touch screen

Positioning accuracy

±1mms

Transmittance

95%

Hardness

7H

Click manner

double points

Response time

10ms

Output Resolution

4096X4096

Life time

more than 60 million

Input and output

VGA

1

HDMI

1

LAN

1

USB

2

Video

Color system

PAL/NTSC/SECAM

Compatible HDMI input/DVI

480P,576P,720P,1080I,1080P

3D Comb filter

Yes

Video reduction noise

Yes

OSD display( screen menu display)

Menu language

Chinese/English( multiple language option required)

Computer

Main chipset

Intel GM45

CPU

Duo core, 2.26G

System bus frequency

800/1066/1333 MHz

Graphics card

Integrated GMX 4500

Audio card

Integrated AC97

Network card

Integrated 10/100/1000M adaptive

Memory

2G DDRIII

Hard Disk

320G SATA

Operation system

Optional

Power

Power supply

AC100V~240V,50/60Hz

Maximum power consumption

100W

Standby power consumption

1W

Temperature

Working temperature

0°C~50°C

Storage temperature

-10°C~60°C

Working humidity

20%~80%

Storage humidity

5%~95%

Appearance

Panel color/appearance

White, black, customized

Panel material

SPCC/Aluminum/Customized
