22 inch advertising floor display with touch screen

FOB Price

US$ 1,000 - 3,000 / Set

1 Set(Min. Order)

Port shenzhen
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Size

22inch

Product Description

Specifications

22 inch advertising floor display with touch screen
Size:19/22/32/42/55inch
Touch:two point touch/optional

22 inch advertising floor display with touch screen

Product Description

Specifications
Model No.					US-T2201HC
Panel size					22" TFT-LCD
Display area(mm)/mode					474x300mm 4:3
Maximum resolution					1680×1050
Display color					16.7M
Pixel Pitch(mm)					0.51(H)×0.51(V)
Brightness (nits)					700cd
Contrast					300:1
Visual angle					178°/178°
Response time					8ms
Horizontal frequency					50-70KHZ
Vertical frequency					56-75KHZ
Life(hrs)					>60,000(hrs)
Touch Panel
Specification					Infrared touch
Positioning accuracy					±2mms
Transmittance					≥92%
Hardness					7H
Click manner					double point/mult-point(optional)
Response time					10ms
Output Resolution					4096X4096
Life time					Single point of more than 600 million times
Input and output
VGA input					2
CVBS input					2
YPbPr input					1
TV					1
HDMI					4
USB2.0					6
LAN					1
PC Audio					1
Audio(L/R) input					1
Audio(L/R) output					1
Speaker					2×10W(8 ohm)
Video
Color system					PAL/NTSC/SECAM
Compatible HDMI input/DVI					480P,576P,720P,1080I,1080P
3D Comb filter					Yes
Video reduction noise					Yes
OSD display( screen menu display)
Menu language					Chinese/English
Computer
Main chipset					Intel H61
CPU					Intel I3-2100 3.1G
System bus frequency					800/1066/1333 MHz
Graphics card					Integrated
Audio card					Integrated AC97
Network card					Integrated 10/100/1000M adaptive
Memory					2G DDRIII (max 4G)
Hard Disk					320G SATA
WIFI					Optional
Bluetooth					Optional
Operation system					Windows 7
Power
Power supply					AC100V~240V,50/60Hz
Maximum power consumption					230W
Standby power consumption					3W
Temperature
Working temperature					0°C~50°C
Storage temperature					-10°C~60°C
Working humidity					20%~80%
Storage humidity					5%~95%
Appearance
Cabinet color/appearance					White, black, customized
Cabinet material					SPCC/Aluminum/Customized
Installation					Floor-standing
Unit price					USD( FOB Shenzhen)
Bulk Order Leading time					within 21working days
Payment terms					T/T
Warranty					1year
Valid time					10days
