Home > Products > Aluminum Cylinder > 6.8L Carbon Fiber Cylinder,scba Cylinder With Full Face Gas Mask

6.8L Carbon Fiber Cylinder,scba Cylinder With Full Face Gas Mask

FOB Price

US$ 80 - 300 / Piece

50 Pieces(Min. Order)

Port Ningbo Dalian Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Aluminium	Use	Oxygen
Pressure	High	Place of Origin	Zhejiang, China
Brand Name	tianen	Model Number	CRPIII-145-6.8-30-T

Product Description

SCBA gas cylinder

6.8L carbon fiber cylinder

Specification: CRP III -145-6.8-30-T

Outside Diameter: 157mm

Water Volume: 6.8L
Length: 528mm
Weight: 4.1kg

Working Pressure: 300bar

Certificate: CE, TS

Third party Inspectors: TUV, CSEI, SGS

Filling content: Air, O2

Color: As shown in the picture or custom.

Thread: M18×1.5 or custom.

Form A, Form E available.

No.	Specification	Outside Diameter	Water Volume	Length	Weight	Working Pressure	MOQ
1	CRPIII-114-2.0-30-T	114mm	2.0L	321mm	1.6kg	300bar	50
2	CRP III-120-2.4-20-T	128mm	2.4L	302mm	1.8kg	200bar	5
3	CRP III-120-2.5-20-T	128mm	2.5L	312mm	1.9kg	200bar	5
4	CRP III-124-2.7-20-T	132mm	2.7L	310mm	1.9kg	200bar	50
5	CRP III-114-3.0-30-T	114mm	3.0L	446mm	2.1kg	300bar	50
6	CRP III-145-6.8-30-T	157mm	6.8L	528mm	4.1kg	300bar	5
7	CRP III-161-9.0-30-T	174mm	9.0L	560mm	5.2kg	300bar	5
8	CRP III-180-12.0-30-T	196mm	12.0L	605mm	6.5kg	300bar	5
9	CRP III-200-20.0-30-T	222mm	20.0L	770mm	12kg	300bar	50

Seamless aluminum ally 6061 liner wound with high strength Japan-imported carbon fiber and glass fiber reinforced plastic full composite layers and subjected to an autofrettage pressure. The high strength and safety-assured construction provides up to 300bar service pressure, which enlarges gas storage capacity to 1.5-2 times than that of aluminum or steel cylinders;

Extremely Light weight, up to 60%-70% lighter than steel cylinders and 30-40% lighter than aluminum cylinders;

No magnetism;

High corrosion resist and special inner surface treatment, ensure storage gas clean and smelless;

Stable performance;

The specifications of carbon fiber composite cylinders behind covers a wide range of applications such as Self-contained breathing apparatus (SCBA), paintball gun, home oxygen therapy, aircraft oxygen, ELSA escape sets, and other applications that require lighter weight, stronger corrosion-resistance inner surface, and higher gas storage capacity.;

Choice of worldwide top brands and enterprises.
