Popular Mining Processing Equipment in Thailand / Copper Ore Flotation Machine
USD $565 - $20,000
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- Qingdao Tianjin Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
-
Henan Ruiguang XJK Series Mineral Process Flotation Machine
-
Henan Ruiguang Mining Use Mixing Tank
-
Mining Ores Process Equipment/ Henan Ruiguang Mixer
-
Mining Ores Processing Flotation Equipments/ Flotation Machine
-
Sand & Stone Production Line / Ruiguang Mining Usage Vibrating Screen Mesh
-
High quality trommel screen with small tilt angle to avoid jam
Product Details
| Condition | New | Type | Flotation Separator | |
| Place of Origin | Henan, China | Brand Name | Ruiguang | |
| Model Number | RG-FM91 |
Product Description
Specifications
Flotation Machine1. ISO9001: 2000
2. good quality
3. stable performance & energy-saving
4. copper/ silver/ gold processline
good quality mining flotation machine
1,Introduction Of Flotation Machine
This type of flotation machine is formed by U through solid, hollow shaft inflation, suspension rotor and new type impeller. The cone impeller lean backwards, the blending quantity is big and the pressure head is small, the advantages are: simple structure and low energy consumption. Inside the impeller, there is air distributor, which distributes air into most parts of impeller evenly.
2,Working Principle Of Flotation Machine
When flotation machine works, slurry is inhaled from the bottom of the trough to the space between impellers. Meanwhile, the low pressure air send by fan is sent to this area through the air distributor in the hollow shaft. After sufficient mixing, the slurry is pushed out by the impeller, and then goes to the whole trough.
3.Main Technical Parameters of XJK Series Flotation Machinery
| Model | XJK-0.35(3A) | XJK-0.62(4A) | XJK-1.1(5A) | XJK-2.8(6A) | XJK-5.8(7A) | ||
| Effective Volume(m3) | 0.35 | 0.62 | 1.1 | 2.8 | 5.8 | ||
| Capacity(m3/min) | 0.18~0.4 | 0.3~0.9 | 0.6~1.6 | 1.5~3.5 | 3~7 | ||
| Rotate Speed(r/min) | 470 | 400 | 330 | 280 | 240 | ||
| Impeller Dia (mm) | 300 | 350 | 500 | 600 | 750 | ||
| Motor | Model | Rotator | Y90L-4 | Y100L2-4 | Y132M2-6 | Y160L-6 | Y200L2-6(Y225M-6) |
| Scraper | Y90S-4 | Y90S-4 | Y90S-4 | Y90S-4 | Y90L-4 | ||
| Power(Kw) | Impeller Motor | 1.5 | 3 | 5.5 | 11 | 22(30) | |
| Scraper Motor | 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | ||
| Weight(t/Single Tank) | 0.43 | 0.86 | 1.38 | 2.33 | 3.533 | ||
