Home > Products > Mining machine > Mineral Ores Separator Machine/ Gold Ore Flotation Machine
Mineral Ores Separator Machine/ Gold Ore Flotation Machine
US$ 3,000 - 200,000
/ Set
1 Set(Min. Order)
- Qingdao Tianjin Shanghai
- T/T L/C D/P D/A Credit Card
You May Like
-
Large-type Dry Ball Mill for Grinding Calcium Bentonite
-
Professional Mineral Process Machinery/ Ruiguang Spiral Classifier for Sale
-
Popular Mining Processing Equipment in Thailand / Copper Ore Flotation Machine
-
Henan Ruiguang XJK Series Mineral Process Flotation Machine
-
Henan Ruiguang Mining Use Mixing Tank
-
Mining Ores Process Equipment/ Henan Ruiguang Mixer
Product Details
| Condition | New | Type | Flotation Separator | |
| Place of Origin | Henan, China | Brand Name | Ruiguang | |
| Model Number | RG-FM41 |
Product Description
Specifications
Flotation Machine1. ISO9001: 2000
2. good process mahcine
3. fine output size
4. for copper/lead/silver/nickel ores
1,Introduction Of Flotation Machine
This type of flotation machine is formed by U through solid, hollow shaft inflation, suspension rotor and new type impeller. The cone impeller lean backwards, the blending quantity is big and the pressure head is small, the advantages are: simple structure and low energy consumption. Inside the impeller, there is air distributor, which distributes air into most parts of impeller evenly.
2,Working Principle Of Flotation Machine
When flotation machine works, slurry is inhaled from the bottom of the trough to the space between impellers. Meanwhile, the low pressure air send by fan is sent to this area through the air distributor in the hollow shaft. After sufficient mixing, the slurry is pushed out by the impeller, and then goes to the whole trough.
3,Main Technical Parameters of Model SF Flotation Machinery
| Model | SF0.37 | SF0.7 | SF1.2 | SF2.8 | SF4 | |
| Tank Volume (m3) | 0.37 | 0.7 | 1.2 | 2.8 | 4 | |
| Impeller Dia (mm) | 300 | 350 | 450 | 550 | 650 | |
| Capacity (m3/min) | 0.2-0.4 | 0.3-0.9 | 0.6-1.2 | 1.5-3.5 | 0.5-4 | |
| Impeller Rotate Speed (m3/min) | 352 | 400 | 312 | 268 | 238 | |
| Motor | Model | Y90L-4 | Y100L2-4 | Y132M2-6 | Y160L-6 | Y180L-6 |
| Y90S-4 | Y90S-4 | Y90S-4 | Y90S-4 | Y90L-4 | ||
| Power (Kw) | 1.5 | 3 | 5.5 | 11 | 15 | |
| 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | ||
| Overall Dimension (mm) | 700×700×750 | 900×820×950 | 1100×1100×1100 | 1700×1600×1150 | 1850×2050×1200 | |
| Unit Weight (kg) | 468 | 600 | 1373 | 2338 | 2660
| |
Main Technical Parameters of XJK Series Flotation Machinery
| Model | XJK-0.35(3A) | XJK-0.62(4A) | XJK-1.1(5A) | XJK-2.8(6A) | XJK-5.8(7A) | ||
| Effective Volume(m3) | 0.35 | 0.62 | 1.1 | 2.8 | 5.8 | ||
| Capacity(m3/min) | 0.18~0.4 | 0.3~0.9 | 0.6~1.6 | 1.5~3.5 | 3~7 | ||
| Rotate Speed(r/min) | 470 | 400 | 330 | 280 | 240 | ||
| Impeller Dia (mm) | 300 | 350 | 500 | 600 | 750 | ||
| Motor | Model | Rotator | Y90L-4 | Y100L2-4 | Y132M2-6 | Y160L-6 | Y200L2-6(Y225M-6) |
| Scraper | Y90S-4 | Y90S-4 | Y90S-4 | Y90S-4 | Y90L-4 | ||
| Power(Kw) | Impeller Motor | 1.5 | 3 | 5.5 | 11 | 22(30) | |
| Scraper Motor | 1.1 | 1.1 | 1.1 | 1.1 | 1.5 | ||
| Weight(t/Single Tank) | 0.43 | 0.86 | 1.38 | 2.33 | 3.533 | ||
