Home > Products > Electric tube furnace > Vacuum system (ZK-J)
Vacuum system (ZK-J)
- Shanghai
- T/T
You May Like
Product Details
| Brand Name | SIOMM | Model Number | ZK-J | |
| Place of Origin | Shanghai, China |
Product Description
Specifications
1. Vacuum system2.High temperature vacuum sintering
3.Latest technique
4.1 year warranty
5.CE approved
Vacuum system (ZK-J)
Technical Parameter:
ZK -J vacuum system is composed of built - in bipolar rotary vane mechanical vacuum pump, resistance vacuum gauge (also called pirani gage) and resistance gauge which processed by special stabilization. With high accuracy, good stability and strong anti-interference ability. The display of vacuum degree adopted scientific notation, digital display and intuitive, easy to use. Exhaust port and the gas line connection port adopted KF -style quick connect structure to simplify the installation process and easy to operate. The vacuum control system can be used with our vacuum electric tube furnace and gas flow control system.
Main uses:
To obtain the high vacuum for high temperature vacuum sintering, atmosphere CVD experiments, vacuum annealing and material handling.
Technical Parameter:
Model | ZK-J (Approved by CE certificate, ensure the safety operation of the machine. Certificate No.: GB/1067/4189/12 Issue 1) |
Vacuum degree | 1-10Pa |
Ultimate vacuum | 0.1Pa |
Configuration | Double stage rotary vane vacuum pump |
Measuring type | Resistance vacuum gauge |
Vacuum gauge tube | Resistance gauge |
Power supply | AC380V 50/60HZ |
Pumping speed | 4L/S |
Standard configuration | Corrugated tube 1 piece, KF25 vacuum angle valve 1 piece, KF flange 1 piece, double stage rotary vane vacuum pump 1 set, hoop 5 pieces, vacuum gauge 1 piece. |
Packing :Plywood box with foam
