WFJ-30/60/80/110 Micro pharmaceutical pulverizer

Place of Origin	Jiangsu, China		Brand Name	WX
Model Number	WFJ		Application	Capsule
Type	Concentrator		After-sales Service Provided	Overseas service center available

Specifications

1. Micro pharmaceutical pulverizer
2.Model:WFJ-30/60/80/110
3.Size of input:less than 10
4.size of output:60-450



skype:lisachen978

WFJ-30/60/80/110 Series Micro pharmaceutical pulverizer



Main Application:

WFJ-30/60/80/110 Series Micronizer consists of main motor,auxiliary motor and electrical control cabinet.It has the features of compact design ,simple structure,winnowing, and non-sieve or mesh.The negative pressure brings heat and particles out,so it is especially well applied in the industry of chemical,food stuff,pharmaceutics,cosmetics,fuel,resin and etc.Its performance is up to the international advanced level.

Operating Principle:

The material is sent to grinding chamber through hopper and screw conveyer, and then pulverized by high speed rotary blades.Processed fine material are winnowed and collected by the negative pressure of an air intake of a blower,dust collector is included.The advantage of it are very little dust,high utilization of the raw material and cost reduction.

Nowadays, Jiangyin Haixiang Machinery Co.,ltd have customers both in China and abroad.Foreign customers such as Russian,East Europe,Middle East,South America,North America,East Asia,Southeast Asia, Africa,etc.



Machine discription:



Model	30	60	80	110
Prodtction Capacity(kg/h)	30-800	50-1200	100-1200	200-3000
Size of input granules(mm)	~10	~10	~15	~20
Size of output granules(mesh)	60-450(adjustable)	60-450(adjustable)	60-450(adjustable)	60-450(adjustable)
Total Power(KW)	46	84.15	145	230
Main running speed	3800	2800	2200	1480
Weight(kg)	2800	4500	9500	16000
Overall Size(L×W×H)	6640×1300×3960	7500×2300×4530	9800×2600×6800	13000×3500×7200



Machine pictures:
