Home > Products > stationary scissor lift platform > Jinchuan Brand New Arrival Hydraulic Stationary Shear Fork Type Lifter
Jinchuan Brand New Arrival Hydraulic Stationary Shear Fork Type Lifter
- QingDao
- T/T
You May Like
-
Hydraulic Rotating Lift Stage
-
Jinchuan Suitable for Maintenance Fixed Scissor Elevator
-
Jinchuan Safe and Practical Hydaulic Double Row Fork Fixed Shear Fork Lift
-
Jinchuan Economic and Practical Hydaulic Fixed Shear Fork Type Lifting Cargo Lift
-
Jinchuan Suitable for Production Line Hydraulic Stationary Scissor Type Elevator
-
China Fixed Shear Fork Lift for Cargo
Product Details
| Place of Origin | Shandong, China | Brand Name | JinChuan | |
| Model Number | SJYG |
Product Description
Specifications
hydraulic shear fork type lifter1.high-strength steel
2.high load and unload
3.easy to control,safe and secure

Product advantages:
Hydraulic lifting system, the remote control and multi-control points at the different floors could be realized. Lift Up,Stop and Lower could be realized at each control point. The lift platform could stop at the accurate loaction point. Smooth working condition,high load capacity, safe and reliable. The overload protection devices are available and meanwhile the hydraulic system has the anti-drop function when any failure happens.
Applications:
It is drived by the electric and hydraulic system, the lift platform is lifted up and drops down along the track;It is installed in the pit or the ground floor to convey the goods from one floor to another and convey the goods from one working level to another. The control panels are available at the designated floors and one the lift platforms. The multi-control points are realized, the lifting height are accurate and it work smoothly.The lifting capacities widely range from 200kg to 15 tons.
This model of scissor lift is designed and produced on the special requirement from customers, on four aspects: carrying capacity, lifting height, dimension of table, and power supply.
They have two mainly types for different sites. One is to be sited on a special place to loading cargos and lifting to a certain height to handle and move cargos.
Model
| Table hoisting effective altitude (m) | Rated load(kg) | table size (L*W)(mm) | Max overall dimensions (L*W*H)(mm) | supporting power (kw) | Entire weight(kg) |
SJYG0.3-3.0 | 3 | 300 | 1650-1000 | 1650*1000*680 | 2.2 | 400 |
SJYG0.5-6.5 | 6.5 | 500 | 2400*1500 | 2400*1500*1000 | 2.2 | 1200 |
SJYG2-4.0 | 4 | 2000 | 2560*2200 | 2560*2200*680 | 3.0 | 2500 |
SJYG3.0-4.0 | 4 | 3000 | 6000*3000 | 6000*3000*1000 | 7.5 | 4000 |
SJYG10-4.5 | 4.5 | 10000 | 3000*2700 | 3000*2700*1250 | 5.5 | 4500 |
