high quality Phylon midsole vulcanizing machine
- 200 Set / Sets per Month
- qingdao china
- T/T
You May Like
Product Details
| Condition | New | Type | Vulcanizer | |
| Place of Origin | Shandong, China | Brand Name | eenor | |
| Model Number | all various | Voltage | 220v-500v | |
| Certification | ISO9001:2008 SGS | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Reduce the laborEasy Installation
automatic and manual work style
high production
Frame Type rubber Vulcanizing Machinery is used for vulcanizing all kinds of rubber and plastic mould products, and non-mould products. Being frame type, the machine is different from the column type , it is allowed to install larger diameter hydraulic cylinder, reducing the quantity of cylinders, with simple structure, and little maintaince work. The frame can bear more stress and it has cheap price, nice surface, easy to operate.
Phylon midsole vulcanizing is used to produce various Phylon midsole,EVA foam slippers,foam sheet, insulation materials, sports protective material, life jackets, sponges and other thermoset rubber products.
Our main products are plate vulcanizing press, rubber machine, conveyer belt vulcanizing press, tyre retreading machine, rubber tiles vulcanizing press, tire building machine, rubber kneader, two-roll mixing mill and so on.
We 100% real manufacture,more than 30 years experience,CE,ISO Certification make us become credible.
Hydraulic and electrical components apply international standard,you can find small component in your city.
The Main Technical Parameter:
Type | XLB-DQ1200×1250×6/8.0 MN |
Total Pressure (Ton) | 800 |
Plate Size (mm) | 1200×1250×70 |
Daylight (mm) | 150 |
Plate Unit Pressure (Mpa) | 5.5 |
Layer | 6 |
Piston Stroke (mm) | 900 |
Close Mould Speed (m/s) | ≥15 |
Open Mould Speed (m/s) | ≥300 |
Hydraulic System Pressure (Mpa) | 18.1 |
Cylinder Diameter (mm) | Φ750 |
Cylinder NO. (Set) | 1 |
Motor Power (kw) | 15×2+11 |
Weight (kg) | 32500 |
the plate size we can accoring to clients request customize.
