Home > Products > 75ohm coaxial cable > High quality coaxial cable rg179 Trynew
High quality coaxial cable rg179 Trynew
- NINGBO/SHANGHAI
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | CHAUNGYUAN/OEM | |
| Model Number | RG213 | Type | Coaxial | |
| Number of Conductors | 1 |
Product Description
China supplier competitive price low loss RG179 coaxial cable, RG 179coaxial cable, RG179 siamese cable
Construction & Basic Characteristics
1) Construction | ||
Center Conductor: | 7*0.1mm(0.48mm) SC/TS | |
Dielectric: | 1.6mm±0.05mm PE | |
Shield: | SC Braiding | |
Braid Coverage: | 95% | |
Jacket: | 2.54±0.10mm PVC | |
Jelly/APD | Per Customer’ Special Requirement | |
2) Characteristics | ||
Sparker Test: | 4000VAC | |
Impedance: | 50±2 Ohm | |
Capacitance: | 64±3pF/m | |
Velocity of Propagation: | 69.5% | |
Return Loss: | 22dB min (5-1000MHz) | |
Attenuation | [@68o F. (20o C.)] | |
Frequency (MHz) | Maximum (dB/100 ft.) | Maximum (dB/100 m) |
10 | / | / |
100 | 7.66 | 26.8 |
400 | 15.69 | 54.9 |
1000 | 25.23 | 88.3 |
2000 | / | / |
3000 | / | / |
Length: 100m/200m/305m/500m, according to your requirements;
Packing: coil/ paper reel/plastic reel/wooden drum, ect.
1.OEM Available
2.ISO9001/CE/RoHS Approved
3.Good quality with best service
4.Free Sample
5.Fast delivery
