Home > Products > Sewage suction truck > Sewage Truck JHL5251GXW 16CBM
Sewage Truck JHL5251GXW 16CBM
- Tianjin Shanghai Qingdao
- T/T
You May Like
Product Details
| Transmission Type | Automatic | Condition | New | |
| Emission Standard | Euro 3 | Fuel Type | Diesel | |
| Tank Volume | 16CBM | Dimension (L x W x H) | 9400*2480*3800 | |
| Place of Origin | Shandong, China | Brand Name | STEYR | |
| Model Number | JHL5251GXW | Horsepower | 266 | |
| Gross Vehicle Weight | 25000 |
Product Description
Specifications
Sewage truck JHL5251GXW 16CBMSewage suction truck
powerful vacuum suction device
pressure discharge
advanced tech
Sewage truck JHL5251GXW 16CBM
Sewage suction truck
powerful vacuum suction device
pressure discharge
advanced tech
Characteristic:
This kind of sewage suction truck is purchased several times and large quantity by UN pace keeper. And received a good reputation and credit. You also can choose the Howo chassis. We also can design and produce combination truck.
High pressure washing and suction combination truck is mainly used for sewage pipe and industrial pipe dredging, river slurry removal and industrial washing operations. The truck uses high pressure water jet to remove dirty and blockage objects. The combination truck is also equipped with powerful vacuum suction device. It uses vacuum suction and pressure discharge, so it has high efficiency and saves time. Volume of its tank body is 10-20m3
No. | Item | Unit | Value/ Content |
1 | Type |
| JHL5251GXW |
2 | Chassis model |
| ZZ1256M4646C |
Drive style |
| 6*4 | |
3 | Engine power | kw | 196/213 |
4 | Overall dimensions(L*W*H) | mm | 9400*2480*3800 |
5 | Tank dimensions(Diameter*Width) | mm | 2050*6600 |
6 | Tank capacity | m3 | 16 |
7 | Axle distance | m | 4325+1350 |
8 | wheel base(front/rear) | mm | 1939/1800 |
9 | Front overhang | mm | 1560 |
10 | Rear overhang | mm | 2133 |
11 | Max speed | km/h | 90 |
12 | complete vehicle kerb mass | kg | 11650 |
13 | total mass | kg | 25000 |
14 | Diameter of suction tube | mm | 100 |
15 | Suction depth | m | ≥8 |
16 | Opening angle of the rear tank door | . | 60 |
17 | Lift angle of tank | . | 30 |
vacuum pump | Type |
| vane pump |
pumping rate | m3/h | 318 | |
rated speed | rpm | 1300 | |
Max pump vacuum rate | Absolute Value | 10 | |
% | 90 |
