Frozen Sucker/Ice Sucker/Jelly Packaging Machine/Wrapping Machine

FOB Price

US$ 1 - 15,000 / Unit

1 Unit(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Food
Packaging Type	Other, pillow package	Packaging Material	Other, BOPP+PE, BOPP+CPP
Automatic Grade	Automatic	Driven Type	Electric
Voltage	220V	Power	3.66kw
Place of Origin	Shandong, China	Brand Name	Fengye
Model Number	FC450/120	Dimension(LWH)	47509651750MM
Weight	1200KG	Certification	SGS
After-sales Service Provided	Engineers available to service machinery overseas

Frozen Sucker/Ice Sucker/Jelly Packaging Machine/Wrapping Machine

This is an inverted version of a horizontal wrapper with reel holders below machine body.

FC works with film invert feeding.

Application:

A wide range of applications such as : multi-piece packing, i.e. sausage, instant noodle, soaps,

hardware and so on.

Features:

1. Compact design and easy operation.

2. Automatic on-site stop.

3. Digitally indicating the size of the film, speed of wrapping, turnout and temperature.

4. English-chinese touch screen.

5. Speed control via A.C. invertors.Film control via servo motor.

We also can supply the machine with two servo motors.

6. Photoelectric cell and dual tracking without mechanical contact.

Technology Parameter:

Model	FC450/99	FC450/120	FC450/150	FC590/120	FC590/150	FC590/180
Roll Max. Width in mm	450	450	450	590	590	590
Product Measurement in mm	L: 90-400 W: 10-150 H: 5-40	L: 90-400 W: 10-150 H: 15-60	L: 90-400 W: 10-150 H: 40-90	L: 90-400 W: 30-200 H: 30-60	L: 90-400 W: 30-200 H: 40-90	L: 90-400 W: 30-200 H: 60-120
Capacity, Bags/Min	50-180	50-150	50-150	50- 150	50 150	50-150
Machine Dimensions	50009651750			500011051750
Types of Packaging Composite Film	Packaging Composite Film, PE/Paper, OPP/PE, ALU/PE and ETC
Machine Weight	1000 kg			1200 kg
Power Required	220V/AC, 1 phase, 50 Hz. 3.66 KW

We have the most professional technology ( more than 20 years ) and most serious attitudes for our packing machines.
