SINBON Automatic Liquid Filling Machine

FEATURES

Digital-Filler use a gear pump concept as a metering device to fill correct amounts of gel or liquids into containers

Filling volume, filling speed, interval time can be changed according to filling requirement

Two filling speed levels, Fast filling at the beginning and slow filling at the end to eliminate the bubbles

Human interface is achieved using a combined keypad and LCD display configuration

20 Product preset and easy to edit and recall

Pump unit easily dismantled for cleaning

Installed with conveyor to be automatic filling machine

APPLICATION

Used in the pharmaceutical industry, food industry, cosmetics, agriculture and other industries, such as  fruit and vegetable drinks, soy milk, acetone, glutaraldehyde, shampoo, etc.

SPECIFICATION

Model No.: DLF-100-2H

Filling Volume: 10ml-11,000ml/Time

Filling Speed: 100ml 40P/min.; 300ml 30P/min.; 1000ml 18P/min.

Accuracy :±0.5-1.0%

Belt Width: 80mm/200mm

Air Source: 5-6kg/cm2; 100L/min.

Power Source: AC220V; 50Hz; 1P; 1200W

Dimension: 2400x800x1300mm

Net Weight: 120kg

 Note: Digital Liquid Filling Machine can achieve simultaneously promote the nozzle during the filling period when using a belt conveyor, effectively to reduce the bubbles. (The start time of enhance and the speed both can be adjusted)
