CK-6132S lathe

Specifications

Zhejiang Zhaoshan Machine Tool Co.,Ltd, which belongs to the China Zhaoshan Group, is located in Zhuji City, Zhejiang Province, China. We are manufacturer of good quality milling machines and lathe machines. Since it founded, we have won ISO9001, ISO14001 and CE, what is more, we were awarded as The High and New Technology Company of Zhejiang.

At the same time, we have developed the formalization, intensified company’s direction. We established Hubei Zhaoshan Machinery Co.,Ltd and Hubei Xiangfan Machine Tool Co.,Ltd, which are located in Hubei Province as our son companies.

CK6132S specifications:
Max. Swing over bed: 320mm (15″)
Max. Swing over cross slide: 174mm (7″)
Max. processing length: 450mm(18″)
Range of spindle speed: 200-3000r/min
Step of spindle speed: no class
Spindle bore:Φ50mm
Spindle nose:C-5
Chuck:Φ160manual three-jaw chuck
Main motor power: 3kw(4.08HP) Induction motor
X-axis travel: 200mm(8″)
Z-axis travel: 460mm(18″)
Rapid feed: 6/8m/min(servo)  4/6m/min(stepping)
Minimum input unit: 0.001mm(servo)  0.01mm(stepping)
Feed motor power X/Z: 4/6Nm(servo)  8/12Nm(stepping)
Positioning accuracy X/Z: 0.01/0.01mm
Repeatability positioning accuracy X/Z: 0.0075/0.01mm(servo)  0.01/0.013mm(stepping)
Standard cutter diameter size: 20*20mm(7/8″*7/8″)
Standard: four-position electric tool turret
Tailstock sleeve travel: 120mm(5″)
Tailstock sleeve diameter: Φ50mm
Inner taper of tailstock: MT No.3
Packing size(L*W*H): 2100*1350*1760mm(83″*53″*70″)
Net weight: 1350kg
Gross weight: 1500kg
