High Quality Double Power Automatic Transfer Switch ATS CMGQ2-80 40A

Use logical control board, with various logic, to manage the operational manipulation of the motor and gearbox mounted inside the switch so as to ensure the switch position.
The motor is of neoprene insulating damp-heat type with safety device, and it will trip off at the temperature of more than 110? and under the condition of over-current. It will work automatically after the fault is gone. Reversible reduction gear is made with straight-wheel teeth.
Good security
Zero flashover is basically realized(without arc-distingu-isher) by adopting double composite contact, transversal-connected structure, micro-motor pre-energy-storage and microelectronic control technology;
Adopt reliable mechanical interlock and electrical interlock technology;
Adopt zero-crossing technology;
Have obvious on-off position indication and padlock functions, which can realize reliably the isolation of power and load;
High reliability with the service life of more than 8000 times;
Electromechanical integrated design, making the switch transferred correctly, flexibly and reliably;
Good electromagnetic compatibility, strong anti-interference ability without interference to outside, and high automation level
The full-automatic type doesn't need connecting externally any control omponents
Smart appearance, small volume and small weight.

CEMIG is one of a company of low voltage smart electrical and global operation, but also a firm advocated of environmental protection appliances. With 10 years of professional experience in low-voltage electrical research and development, production, provide products and solutions aimed on green energy and smart power. Now, it has many branches, a manufacturing industrial park, a R&D center. The distribution channels around the country make the company to better grasp the pulse of the market, well understand the local information, more quickly and efficiently meet customer demand.
