Universal Metal Body XLR Pcb Mount D Series XLR Chassis Connectors NC3MD-V 3 Pole Male Receptacle Quality Choice
- shanghai port or ningbo port
- Credit Card
You May Like
-
Solder Type 3 Pin NEUTRIK Cannon Microphone XLR Connector Female Jack
-
Solder Type 3 Pin NEUTRIK Cannon Microphone XLR Connector Male Plug
-
Red Blue Yellow Neutrik 3 PIN XLR Female Jack,microphone Female Jack,conon Female Jack,speaker Female Jack
-
Plastic Jacket Fits D Series Pattern Holes Vertical PCB Mount Flange Mount 3 Pole 3 Pin XLR Female Connector
-
Plastic Housing Jacket Vertical PCB Mount Flange Mount 3 Pole 3 Pin XLR Male Plug Connector
-
Right Angle Plastic Jacket Fits D Series Pattern Holes Vertical PCB Mount Flange Mount 3 Pole 3 Pin XLR Female Connector
Product Details
| Place of Origin | Jiangsu, China | Brand Name | AIO | |
| Model Number | AIO-P022 | Type | Other, XLR, Audio & Video | |
| Application | Other, Audio & Video | Gender | Male |
Product Description
Specifications
1.ease assembling2. permitting assembling and testing of pcb before assembling into housing
3.Front or rear panel mount
Universal metal body XLR pcb mount series. Unified D-size shell for male and female. Metal shell and 3 ground contacts offer RF protection. Insert is removable from shell for ease assembling. Available in nickel or black housing and silver or gold plated contacts.
Locking mechanism
Latch lock
Grounding
Separate ground contact to mating connector shell and front panel
Front and rear panel mount
Fastening
Panel
Standard: Countersunk mounting holes to accept M3 bolts or rivets
M3 version: M3 tapped thread
Insert on PCB
Self tapping screw, diameter 2.2 mm, max. length 5 mm (e.g. KA22x5)
Panel thickness 1 - 3 mm
Features & Benefits
- D-shape metal shell
- Optimal RF protection using 3 shield contacts.
- Insert is removable from rear of connector and locked into place by internal latch - permitting assembling and testing of pcb before assembling into housing
- Front or rear panel mount
The XLR connector is a style of electrical connector, primarily found on professional audio, video, and stage lighting equipment. The connectors are circular in design and have between 3 and 7 pins. They are most commonly associated with balanced audio interconnection, including AES3 digital audio, but are also used for lighting control, low-voltage power supplies, and other applications. XLR connectors are available from a number of manufacturers and are covered by an international standard for dimensions, IEC 61076-2-103.[1] They are superficially similar to the older and smaller DIN connector range, but are not physically compatible with them.
| |
| Pin | Function |
|---|---|
| 1 | Chassis ground (cable shield) |
| 2 | Positive polarity terminal for balanced audio circuits (aka "hot") |
| 3 | Negative polarity terminal for balanced circuits (aka "cold") |
