R230 Leroy Somer AVR for Generator
- Fuzhou/Xiamen/Shenzhen
- Credit Card
You May Like
Product Details
| Place of Origin | China | Brand Name | parbeau | |
| Model Number | R230 |
Product Description
R230 Leroy Somer AVR for Generator
Automatic Voltage Regulator 100 VDC 8 Amp .R230 8 Amp self excited brushless type genset voltage regulator is an universal AVR and compatible replacement for Leroy Somer R230, R250, R230B, AEM110RE014, Olympian FG Wilson 922 197.
Technical Specification
| Input | Voltage 120(90~140) VAC 1 phase 2 wire |
| Frequency 45~65 Hz | |
| Output | Voltage Max. 100 VDC @ 120 VAC input |
| Current Continuous 8A, Intermittent 10A for 10 sec. | |
| Resistance Min. 15 Ohm | |
| Voltage Regulation | < ±1% (with 4% engine governing) |
| Voltage Build-up | Residual volts at AVR terminal > 5 VAC |
| External Volts Adjustment | ±5% with 5 K Ohm 1/2 watt trimmer |
| Unit Power Dissipation | Max. 6 watt |
| Thermal Drift | 0.03% per °C change in AVR ambient |
| EMI Suppression | Internal electromagnetic interference filtering |
| Under Frequency Protection | Knee point 47/57 Hz (Adjustable) |
| Environment | Operating Temperature : -40~60 °C |
| Storage Temperature : -40~85 °C | |
| Relative Humidity : Maximum 95% | |
| Vibration : 1.5G @ 5~30 Hz / 5.0G @ 30~500 Hz | |
| AVR Controls Functions | VOLT : Voltage Adjustment |
| STAB : Stability Adjustment | |
| U/F*: To Set the U/F Knee Point | |
| (*U/F: Under Frequency Protection) | |
| Shock | Withstands up to 20G in each X, Y, Z axes |
| Dimensions | 140.0 (L) x 75.0 (W) x 51.0 (H) mm |
| Weight | 310g ±2% |
Time of Arrival :Economic DHL for example, (time spending for remote area)
Asian 1-3 Days
Middle EAST:4-6Days
Europ:6-7days
We do not uarantee delivery time on all international shipments due to differences in customs clearing times in individual countries, which may affect how quickly your product is inspected. Please note that buyers are responsible for all additional customs fees, brokerage fees, duties, and taxes for importation into your country. These additional fees may be collected at time of delivery. We will not refund shipping charges for refused shipments.The shipping cost does not include any import taxes, and buyers are responsible for customs duties.
Please choose a shipping method and pay for the order including the shipping fee.
We arrange by DHL normally,special request pls let us know.
Warranty:
Within 2years,if there is any problem with the item,buyers can returns the items to exchange another new one,buyers are responsible for the shipping fees and customs duties. Or add item into your next order by free.
1.Parbeau set up on year 2003,Deal with 80% local market,supply 3000 pcs /Month
2.First AVR Factory in Fuan ,Nearly 10 Years Factory
3.Imported Vima Capacity with other parts from Nation Owned Company
4.Products test: Each product test 3tims before put in Package
5.PE Cover Final Packing for Automatic Voltage Regulator
