Bead Ball Mixer WSZ Vertical InternaL-Cooling Bipyramid

FOB Price

Negotiable / Unit

1 Unit(Min. Order)

Port ShangHai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Mixer Type	Other	Application	Liquid
Additional Capabilities	Drying	Place of Origin	Hebei, China
Brand Name	HUPC	Model Number	WSZ

Product Description

Specifications

bead ball mixer-------WSZ Vertical InternaL-Cooling Bipyramid composed by adjustable inner cooling rotor,jacket stator,spiral

bead ball mixer-------WSZ Vertical InternaL-Cooling Bipyramid

Milling chamber is composed by adjustable inner cooling rotor,jacket stator,spiral return flow tank,dynamic separate.The material(indicate by red arrow head) to into A milling area first through piping,then go into B area,after second milling go into C area.The material flow out through dynamic separate,while the abrasive medium return to A area through spiral return flow tank to form full travel closed circulation

Feature
1. This equipment adopts the principle of slot type milling,so the strength of separate milling power is strong and lasting.This kind of strong extrusion can shear stress can not be done byu normal Sand mill.So it is quite suitable to mill the material which is difficult to separate such as black carbon,iron oxide and with high requirement of finess,such as paint and ink.

2. The milling chamber of bipyramid slot type has the advantage of high efficient milling result,low consumption of abrasive medium ,less residue in the cylinder,low cost for application.

3. Advanced double water cooling system ,it can reach the satisfied cooling result even the tap water used in the warm south.

4. The hand hydraulic system of the cylinder is used it is easy to disassemble for clean.The inverter to adjust the speed to realize the soft,and the different speed can be selected for different material to reach the result of economic energy and good result of milling.

The key technology of this cylinder is to adopt the high wear-resistant alloy which has solved the problem of pollution,caused by the sand mill to material,and the inner lahyer can be changed.

Application range:
1. Automobile paint and repair paint
2. Special ink
3. Colorpaste for water printing
4. Black carbon for textile pigment
5. Sub-micron grade milling
6. Size mixture for electrical industry

Type	Volume (L)	Power (KW)	A(mm)	B(mm)	C(mm)	D(mm)	Weight (kg)	Abrasive Medium (mm)	Output (kg/h)	Cooling water (m³/h)
WSZ-9.8	9.8	22	1180	700	1600	970	1050	0.8-2	60-140	0.8
WSZ-11	11	22	1180	700	1600	970	1100	0.8-2	80-140	1.0
WSZ-14	14	30	1225	720	1700	1020	1250	0.8-2	90-180	1.1
