Home > Products > New Products > Mini 20X Zoom Camera Outdoor PTZ Camera Waterproof Onvif Mini 20X Zoom IP Speed Dome Camera
Mini 20X Zoom Camera Outdoor PTZ Camera Waterproof Onvif Mini 20X Zoom IP Speed Dome Camera
- 1500 Piece / Pieces per Month
- Shenzhen
You May Like
-
PTZ Bullet Camera 2.0 Megapixe 4X CMOS Waterproof Outdoor Zoom AHD PTZ Bullet
-
Auto Focus 20X Optical Zoom H.264 IP IR High Speed Dome Camera 1080P Sony IMX322 CMOS P Pan/Tilt/Zoom
-
4.0MP H.265 HD IP IR High Speed Dome Camera IP66 IR range 120M Network Pan/Tilt/Zoom Camera
-
Auto Focal Lens star light 4X Motorized Zoom 2.0MP Full HD 1080P AHD Color IR PTZ Bullet Camera
Quality Choice
-
Hot !New !Housing 1080P Security AHD Bullet Camera 2.0MP Mini Bullet CCTV Camera
-
New product 2.8-12mm Vari Focal 1080P IMX322 AHD 42pcs LEDs IR 2015 CCTV Bullet Camera
Product Details
| Place of Origin | Guangdong, China | Brand Name | AST | |
| Model Number | ASRIH492-020-20 | Type | IP Camera | |
| Style | Other, PTZ | Sensor | CMOS | |
| Technology | NetWork | Special Features | Waterproof / Weatherproof |
Product Description
Camera
1.1/2.8” 2.0M piexls Sony IMX322 CMOS
2.20X optical zoom, auto focus
3.2.0MP available
4.True Day/Night, 3D DNR, Digital WDR
5.Backlight compensation, and auto gain control (AGC)
6.3D intelligent positioning, 254 programmable presets
Network Features:
1.Max 25/30fps2.0 Megapixels (1920×1080)
2.Support the P2P or Android, IOS
3.Support Onvif2.4
4.H.264 main profile & M-JPEG Dual-stream Encoding ,Three Simultaneous video streams
5.Standard SDK,CGI,easily to be integrated with other digital systems
6.Support a variety of network protocol such as TCP/IP/ HTTP/ NTP/ IGMP/ DHCP/ UDP/ SMTP/ RTP/ RTSP/ ARP /DDNS /DNS/ P2P
Dome Features:
1. NEW 32 bit processor, with soft ID, more storage space, higher speed, better performance, lower consumption
2. Imported array IR LED, auto adjust zoom according to different distance
3. IR range 120M
4. Highest ESD protection against lightning and power surges.
5. 360 degree continued rotation, manual pan speed 1~200°/S, manual tilt speed 1~120°/S, preset speed 400°/S.
| Form parameters | ||
| Mode | Name and Description | H.264 2.0MP HD IP IR Mini High Speed Dome Camera |
| ASRIH492-020-20 | ||
| Camera | Image Sensor | 1/2.8” 2.0M piexls Sony IMX322 CMOS |
| Effective Pixels | 2.0 Mpixes | |
| Min. Illumination | Color:0.05Lux(F1.6, AGC ON) B/W: 0.01Lux(F1.6, AGC ON) | |
| Zoom | 20X , f=4.7mm~94mm, D/N( ICR-Cut) ,F1.6~F3.0 | |
| Day/Night | Day / Night / External control(IR Cut Filter) | |
| SNR | ≥50dB(AGC OFF) | |
| WDR | Digital WDR,≥62.5dB | |
| AGC | Auto / Manual | |
| White balance | Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp | |
| Digital noise Reduction | DNR,3DNR | |
| Shutter speed | 1/2 - 1/20,000s | |
| Network | Video Compression | H.264 Main Profile/M-JPEG |
| Streams | Dual streams | |
| Frame Rate | Main stream: | |
| 1080*1920, 1-25(30fps; 1280*7201, 1-25(30)fps | ||
| Sub-stream: | ||
| 480*640, 1-25(30)fps; 480 *360 1-25(30fps 352*288, 1-25(30)fps; 176*144, 1-25(30)fps | ||
| MJPEG: | ||
| 1280*960, 1280*720, Close | ||
| Bitrate | CBR/VBR, bitrate:32Kbps~10Mbps variable | |
| Audio Compression | G711, PCM | |
| P2P | Android / IOS | |
| Protocols | TCP/IP/ HTTP/ NTP/ IGMP/ DHCP/ UDP/ SMTP/ RTP/ RTSP/ ARP /DDNS /DNS/ P2P | |
| Motion detect | Support | |
| Privacy Zone Masking | Support | |
| Onvif | Onvif 2.4 | |
| Network | 10/100M Base-TX Ethernet, RJ45 Connector | |
| Mini SD Card | Up to 32GB(Optional) | |
| IR | Luminary | Array 42Mil 8pcs |
| Night vision distance | 120M | |
| Support ambient light detection | IR illumination on 1-25 grades selectable; | |
| Dome Features | CPU Type | 32 bit ARM CPU |
| Address | 0~255(soft address and hard address) | |
| Pan Range | 360° continued rotation | |
| Tilt Range | 0°~93° auto flip 180° | |
| Manual pan speed | 1~200°/s | |
| Manual tilt speed | 1~120°/s | |
| Preset speed | 400°/S | |
| Actual preset Accuracy | ±0.10° | |
| Preset points | 255 | |
| Other function | 5 Tour, Intelligent Three dimensional Scan, 5Pattern group ,Operation recall, Manual continued Auto Scan | |
| Intelligent power off real time memory | automatic save functions setting ,automatic wake up tour function | |
| General | Work temperature | Indoor:0ºC~+40ºC Outdoor: -40℃~+60℃ |
| Work Humidity | 0%~90% (Non condensing) | |
| Power | DC12V±10%; 5A | |
| Consumption | < 50W | |
| Related validation | IP66,CE,FCC,RoHs | |
OEM Service:
We could offer OEM and ODM services for our clients.
Delivery Time:
Sample order 3-5 working days, bulk order 7-15 working days.
Quality Warranty:
2 years for free repair. Whole life service for continue cooperating customers!
Price Term:
EXW Shenzhen
Delivery Term:
By Express(DHL/FEDEX/TNT/UPS/EMS/CHINA POST),By air,By Sea.
1. About the sample: How could I get a sample?
Once receive your payment for samples and their express delivery and then send samples
to you. The prices of the samples are the same as those on the pricelist. Express delivery
charge depends on the quantity of the samples.
2. About price list: can I get your price list?
Yes, please tell us the products (with their code number) and order quantity, then we will
offer the price by e-mail. And our price list will keep updated every month.
3. About the shipment: what type of shipment will you use?
We usually ship the products by express delivery to your door or by air freight to your nearest
airport. If the order quantity is large, we may ship by sea container.
4. About payment: what terms of payment do you use?
We accept TT (Telegraphic Transfer,MoneyGramor Western Union as payment term for small
order and L/C for larger order.
5. About the MOQ: What is your minimum order qty?
Our minimum order qty is 20pcs each model, but we accept small order as trial order.
6,About compensation: what is your company's compensation policy?
We can compensate buyer's loss if our products have quality problem. For small qty
problem products, we can replace with new products in next order. For larger qty problem
products, we can accept returned problematic products, then we check them and replace
them by good quality products.
7. About sole-distributor: How can I be your sole-distributor?
We have special policy for sole-distributor. Please contact our sales person to get related files.
8. About OEM: could we place order by OEM style to produce our own brand products in China?
Of course you can. Welcome to do OEM.
If any further problem, welcome to contact our sales person.
Thank for your interest.
