Product Details
| Place of Origin | Shaanxi, China | Brand Name | HT | |
| Model Number | BP93420-IIE |
Product Description
Specifications
Wide range, cast aluminium & explosion-proof housingpressure port
Various output signal, scene adjustable
CE
Description
BP93420IIE pressure transmitter uses HT series piezoresistive silicon oil-filled sensor as the signal measuring element. Signal processing circuit located in the stainless steel housing, can convert sensor signal into standard output signal. All the products through components and semi-finished products test, finished products burn-in screening, are with stable and reliable performance. Have strong anti-interference performance, can working in harsh environment conditions for long term.
Feature
² Wide range, cast aluminium & explosion-proof housing, various pressure port
² Various output signal, scene adjustable
² Multiple protect, strong anti-interference capability.
² Marking: ExiaIICT6 Ga.
Application
² Compatible with 316LSS,noncorrosive gases & liquids.
² Petroleum industry, chemical industry, metallurgy industry, electric power, hydrology etc.
Specification
Measurement Range | 0~35KPa...~100MPa |
Proof pressure | ≤1.5X rated pressure or 110MPa which ever is less |
Pressure type | Gauge, absolute ,sealed gauge |
Accuracy | ±0.25%(Typical) ±0.5%(Max.) |
Long term stability | ±0.2%F.S/year |
Temperature Error- Zero | ±0.5%F.S, ±1%F.S/°C(Max.) |
Temperature Error -Span | ±0.5%F.S, ±1%F.S/°C(Max.) |
Operating Temperature Range | -20°C~80°C |
Storage Temperature Range | -40°C~120°C |
Power supply | 15~30VDC |
Output signal | 4~20mA 0~10/20mA 0/1~5VDC |
Pressure port | M20×1.5 or customize |
O-ring | Fluororubber |
Cable | Polyethylene |
Insulation resistance | 100MΩ 100VDC |
Protection | IP65 |
