Product Details
| Place of Origin | Shaanxi, China | Brand Name | HT | |
| Model Number | BP93420-IB |
Product Description
Specifications
key words:pressure transmitterFull stainless steel
Protection:IP65;
Various output signal.
CE Certification
Description
BP93420IB pressure transmitter use HT series piezoresistive silicon oil-filled sensor as measurement component. Sensor’s output transferred to standard output signal via integrated amplify circuit. Have high reliability &stability.
Feature
² Wide measurement range, Full stainless steel
² Protection:IP65;
² Various output signal.
² CE Certification
² Scene adjustable.
² Marking : ExiaIICT6.
Application
² Petroleum industry, chemical industry, metallurgy industry, electric power, hydrology etc.
² Boats&ships and aviation industry
² Hydraulic pressure and pneumatic control system
Specification:
Measurement Range | -0.1...0~0.01...~100MPa |
Proof pressure | ≤1.5X rated pressure or 110MPa which ever is less |
Pressure type | Gauge, absolute ,sealed gauge |
Accuracy | ±0.25%(typical) ±0.5%(Max.) |
Long term stability | ±0.1%F.S/year(typical) ±0.2%F.S/year(Max.) |
Temperature Error- Zero | ±0.03%F.S/°C(≤100KPa) ±0.02%F.S/°C(>100KPa) |
Temperature Error -Span | ±0.03%F.S/°C(≤100KPa) ±0.02%F.S/°C(>100KPa) |
Operating Temperature Range | -20°C~80°C |
Storage Temperature Range | -40°C~120°C |
Power supply | 15~30VDC |
Output signal | 4~20mA 0~10/20mA 0/1~5/10VDC |
Pressure port | M20×1.5,G1/2 or customize |
Housing material | 1Cr18Ni9Ti stainless steel |
Diaphragm material | 316L |
O-ring | Fluororubber |
Cable | polyethylene |
Insulation resistance | 100MΩ,100VDC |
Protection | IP65 |
