Silicon Pressure Sensor
- XI'AN
- T/T Credit Card
You May Like
Product Details
| Place of Origin | China | Brand Name | HT | |
| Model Number | HT26V |
Product Description
Specifications
Multiple profilePiezoresistive silicon pressure cell
Low output drift
Description
HT26V isolated pressure sensor, utilizes the piezoresistance effect of diffused silicon to fulfill measuring &controlling pressure of liquids and gases with high accuracy and good stability. Full 316L stainless steel can apply in measuring kinds of liquids and gases those compatible with it.
Feature
Piezoresistive silicon pressure cell
Multiple profile
Constant voltage supply
Low output drift
Application
Measurement pressure of gas and liquid
Measure liquid level
Industry process control
Pressure calibration
Electrical Data
Supply: 10VDC Input Impedance: 6KΩ~20KΩ
Output Impedance: 2.5KΩ~6KΩ Insulation Resistance:≥100MΩ/50VDC
Insulation Voltage:500VAC between the case and electrical connections will not cause damage
Medium Compatible:Liquids, gases which are compatible with 316LSS
Performance Specification
