Home > Products > pressure sensor > Silicon Oil Filled Pressure Sensor
Silicon Oil Filled Pressure Sensor
- XI'AN airport
 - T/T L/C D/P D/A Credit Card

You May Like
Product Details
| Place of Origin | Shaanxi, China | Brand Name | HT | |
| Model Number | HT20 |
Product Description
Specifications
316L stainless steel diaphragmHigh static pressure
High accuracy and stability
Description
HT20 is piezoresistive silicon differential pressure sensor, the main element is a diffused silicon with high stability. It utilizes silicon oil to transfer pressure from 316L stainless steel diaphragm to sensing element. It has high stability, good reliability ,high static pressure. It is widely used in field which measure differential pressure.
Features
Wide measurement range: 0~20KPa~2Mpa
Full 316L.S.S
316L stainless steel diaphragm
High static pressure
High accuracy and stability
Application
Measurement pressure of gas and liquid
Environmental control
Process control
Hydraulic and pneumatic equipment
Chemical products and chemical industry
Electrical Data
Supply :1.5mADC Input impedance:3KΩ~6KΩ
Output impedance:2.5KΩ~6KΩ Insulation resistance:≥100MΩ/50VDC
Insulation voltage:500VAC between the housing and electrical connection will not cause damage
Medium compatible: liquid, gas compatible with 316L stainless steel
Performance Specification
Parameters  | Range:0~35KPa,70KPa,100KPa,200KPa,350KPa,700KPa,1000KPa,2000KPa  | |||
Typ.  | Max.  | Units  | ||
Pressure Non-linearity  | ±0.15  | ±0.3  | %F.S  | |
Pressure Repeatability and Hysteresis  | 0.02  | 0.05  | %F.S  | |
Zero Output  | 0±1  | 0±2  | mV  | |
Span Output  | ≤20KPa  | 50±10  | 50±30  | mV  |
≥35 KPa  | 100±10  | 100±30  | mV  | |
Temperature Error zero  | ≤20KPa  | ±2.5  | ±5  | %F.S  |
≥35 KPa  | ±0.5  | ±1  | %F.S  | |
Temperature Error-Span  | ≤20KPa  | ±2.5  | ±5  | %F.S  |
≥35 KPa  | ±0.5  | ±1  | %F.S  | |
Proof Pressure  | 3X  | Rated range  | ||
Static pressure  | 5X or 5MPa, whichever is less  | -----  | ||
Operating Temperature Range  | -20~80  | °C  | ||
Compensated Temperature Range  | 0~70  | °C  | ||
Storage Temperature Range  | -40~125  | °C  | ||
Note :Above parameter under condition:Supply: 1.5mA Temperature:25°C
