ductile iron self-restrained pipe
- 200000 Ton / Tons per Month
- china main ports
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shanxi, China | Brand Name | allwin | |
| Model Number | DN80-DN2000mm | Length | 6m/5.7m | |
| Standard | ISO2531 EN545 EN 598 | Application | water,oil | |
| Diameter | dn80-dn2000 | |||
| Hardness | 230 | Pipe Wall Thickness | K7,K8,K9,K12 | |
| Pull Strength | 420 | |||
| Type | Other, self-restrained, self-restrained |
Product Description
Specifications
ductile iron socket spigot pipe K91.range dn80mm-dn2000mm
2.standard: ISO2531 and EN545
3.T type
Ductile Iron Self-restrained Pipes
Description:
(1) Material:ductile iron
(2) Standed:ISO2531-1998,EN545/598(3) DN80-DN2000mm
(3) Class: K7,K8,K9,K12
(4) Coating:
Inner cement: Ordinary Portland Cement according to ISO4179, Sulphate Resistant Cement or High Alumina Cement Mortar Lining;
Outside coating: Zinc coating(≥130/m2) and bitumen paiting or epoxy paiting(≥70μm) according to ISO8179
(5) Joint type: self-restrained
(6) Gasket: 100% SBR/NBR/EPDM rubber gaskets in accordance with ISO4633.
(7) Testing: factory inspection report,SGS inspection and the third inspection party.
Packing: Pipes from DN100 to DN300 in bundles, DN350-DN2000 in bulk ship.
Payment term: L/C, T/T.
If you are intrested in our products, please contact me any time.
