Product Details
| Place of Origin | Guangdong, China | Brand Name | VANCH | |
| Model Number | VI-89F |
Product Description
RS232 long range uhf rfid integrated reader for waste bin management system
reading distance about 8-10m
rs232, tcp/ip, wiegand26/34
Introduction:Application: logistics, access control, parking management, manufacturing control and etc
Freatures:Reliable industry structure design, workable in varied severe environment.
Model# | VI-89F |
Performance Index | |
Frequency range | 902-928MHZ(or customized) |
FM mode | FHSS or fixed frequency, set by the software |
RF output | 30dBm adjustable;50Ω load |
Communication interface | RS232,RS485,Wiegand26/34(TCP/IP) |
Communication rate | Serial port 9600~115200bps,RJ45 10Mbps |
GP I/O interface | 12 pin + 4 pin |
Power dissipation | average<10W |
Application software | Provide with API SDK and VC, VB, Java application routines |
Tag Operation Performance | |
Reading distance | 6~10m equipped with 9dbi antenna(tag dependent) |
Air interface | EPC global UHF ISO-18000-6C(EPC G2), ISO-18000-6B |
Mechanical and Electrical Performance | |
Dimension | 306(L)*306(W)*25(H)mm(excluding mounting bracket and external wiring) |
Power supply | Equipped with power convertor 220V AC input, +9V/3A DC output |
Weight | 2.6Kg |
Installation | Embrace rod mounting |
Diameter of support rod | 40-50mm |
Humidity | 5% to 95%, non-condensing |
Protection grade | IEC IP65 |
Operation temperature | -20 ºC to +60 ºC |
