Product Details

Place of Origin	Hebei, China	Surface Treatment	Oxidized
Alloy Or Not	Is Alloy	Al (Min)	85-90%
Conductivity	61.3%	Brand Name	Generalmesh
Model Number	CCAW	Application	electrical contact material and conductors
Wire Gauge	0.8mm to 9.5mm

Product Description

Copper-clad aluminium (CCA) wire is available with 10% or 15% copper cladding over an aluminium wire core. Copper-clad aluminium wire offers the inherent characteristics of aluminium while the copper cladding provides greater conduction of current and the ease of soldering of copper.

Copper-clad aluminium

Alloy	Chemical composition	Ultimate tensile strength	Electrical conductivity IACS 20°C (68°F)	Electrical resistivity	Density	Coefficient of thermal expansion
10%CCA	10% Copper by volume	82.7 Mpa (12.0 ksi)	62.854	2.74 Ohms cm 10-6 (16.5 Ohms cir-mil/ft)	3.32g/cc (0.12 lb/in)	22.9 µm/m-°C (12.7 µin/in-°F)
15%CCA	15% Copper by volume	117 Mpa (17.0 ksi)	64.416	2.67 Ohms cm 10-6 (16.1 Ohms cir-mil/ft)	3.63g/cc (0.131 lb/in)	22.9 µm/m-°C (12.7

ADVANTAGES:

• The bimetallic wire integrates the beneficial properties of good conductivity of copper & light weight of aluminium in a single wire called CCA wire

• CCA wire can be easily processed to fine or flat wire

• The density of CCA is about 37-40 % of that of copper. Its length is 2.45 – 2.65 times of copper in the same weight & diameter. These factors reduce the raw material cost for cable manufacturers.

• Environment friendly, CCA saves the copper resources & its production is a nonpolluting process.

• CCA is easy to transport & install as its light weight.
