Wire Spiral Hydraulic Rubber Hose
US$ 1 - 6
/ Meter
500 Meters(Min. Order)
- Shanghai tianjin
- T/T
You May Like
-
Industrial Rubber High Pressure Flexible Water Jet Hose
-
Hydraulic High Pressure Rubber Hose
-
Hydraulic High Pressure Rubber Hose( Competitive Price)
-
Flexible High Pressure Hydraulic Rubber Hose (competitive Price)
-
Flexible High Pressure Hydraulic Rubber Hose (hot Sale)
-
Flexible High Pressure Hydraulic Rubber Hose (high Quality)
Product Details
| Place of Origin | Hebei, China | Brand Name | Tiger | |
| Model Number | rubber hose |
Product Description
Specifications
Wire Spiral Hydraulic Rubber Hose1.flexible,durable and long life
2.apply in industry
3.high pressure and oil resistant
Wire Spiral Hydraulic Rubber Hose
Structure of wire spiraled hydraulic rubber hose
Tube: Oil resistant synthetic rubber
Reinforcement: One to six high tensile steel wire spiral layers
Cover: Abraision and weather resistant synthetic rubber
Temperature range: -40 °C-—+125 °C
The characteristics of wire spiraled hydraulic rubber hose
1.High pressure resistance
2.High temperature resistance
3.Soft and portable
4 Deformation resistant
5 Beautiful appearance
6 Striated, smooth or cloth surface
7 Good Insulation and abrasion resistance
8.Steel wire braided or spiraled layers reinforcement
9.Durable with high quality
10.Free sample
11.Fast delivery
Different kinds of wire spiraled hydraulic rubber hose
Applied in many areas of life production, including: water pipe, water pipe, steam pipe, the sea tube, food and beverage pipe
Technical Specifications:
| Hose size | Hose I.D | Hose O.D | Layer O.D | Working Pressure | Min Brust Pressure | Min Bend Radius | Unit weight | |||
| Ply*Innerdiameter*Pressure | mm | mm | mm | PSI | Mpa | PSI | mm | Kg/m | Ib/ft | |
| Mpa | ||||||||||
| 4SP-φ6-61.5 | 6±0.5 | 19±1.0 | 14.4±0.5 | 61.5 | 8911 | 246 | 35644 | 130 | ||
| 4SP-φ10-52 | 10±0.5 | 24±1.0 | 19.2±0.8 | 52 | 7535 | 208 | 30139 | 160 | ||
| 4SP-φ13-50 | 13±0.5 | 27±1.0 | 22.2±0.8 | 50 | 7245 | 200 | 28980 | 210 | 1.395 | 0.087 |
| 4SP-φ16-50 | 16±0.5 | 30±1.5 | 26±0.8 | 50 | 7245 | 200 | 28980 | 260 | 1.589 | 0.1 |
| 4SP-φ19-46 | 19±0.5 | 35±1.5 | 30±0.5 | 46 | 6665 | 184 | 26661 | 280 | 2.272 | 0.142 |
| 2SP-φ19-21 | 19±0.5 | 31±1.5 | 27±0.5 | 21 | 3043 | 84 | 12172 | 280 | 1.491 | 0.093 |
| 4SP-φ25-35 | 25±0.5 | 41±1.5 | 36±0.5 | 35 | 5071 | 140 | 20284 | 360 | 2.659 | 0.166 |
| 2SP-φ25-21 | 25±0.5 | 38±1.5 | 33±0.5 | 21 | 3043 | 84 | 12172 | 360 | 1831 | 0.115 |
| 2SP-φ32-20 | 32±0.5 | 49±1.5 | 44±0.5 | 20 | 2898 | 80 | 11592 | 460 | 2.195 | 0.137 |
| 4SP-φ32-32 | 32±0.5 | 52±1.5 | 47±0.5 | 32 | 4636 | 128 | 18547 | 560 | 3.529 | 0.221 |
| 4SP-φ38-25 | 38±1.0 | 56±1.5 | 50.8±0.7 | 25 | 3622 | 100 | 14490 | 560 | 4.118 | 0.258 |
| 4SP-φ51-20 | 51±1.0 | 69±1.5 | 63.8±0.7 | 20 | 2898 | 80 | 11592 | 720 | 5.71 | 0.358 |
| 2SP-φ51-14 | 51±1.0 | 65±1.5 | 60.8±0.7 | 14 | 2028 | 48 | 8114 | 720 | 3.81 | 0.234 |
PHOTOS OF High-pressure rubber hose :
re
Wire Spiral Hydraulic Rubber Hose
If you have any kind of question , please feel free to contact us .Your any kind of question will get our first attention .
