Forklift attachment foam clamp
- 300 Set / Sets per Month
- Shanghai Ningbo or others
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Anhui, China | Brand Name | Handbarow | |
| Model Number | HMJ2300 |
Product Description
Functions and application
Forklift attachment foam clamp can safely and effectively handle and stack any kind of foam products e.g. Foam, rubber or soft package cargoes in the fields of rubber, chemical industry and chemical fiber, etc.
Features
- Reasonable structural design, stable operation and improving working efficiency;
- Built-in side shifter further facilitates operation;
- Adjustable synchronism of clamping arms, easy to maintain;
- Excellent operation vision.
Technical Date:
Capacity@ Load Center (Kg@ mm) | Catalog Order No. | Mounting Class | Opening Range (mm) | Frame Width A (mm) | Min. Truck Carriage Width B (mm) | Arm Height H (mm) | Arm Length L (mm) | Vertical Center of Gravity VCG (mm) | Weight (kg) | Effective Thickness ET (mm) | Horizontal Center of Gravity HCG (mm) |
2000@600 | HMJ2300 | II/III | 900-2250 | 1200 | 1045 | 400 | 2000 | 310 | 480 | 200 | 260 |
2000@600 | HMJ2600 | II/III | 870-2600 | 1200 | 1045 | 400 | 2000 | 310 | 550 | 200 | 270 |
Remarks:
1. Please get the actual comprehensive loading capacity of forklift and attachment from the factory;
2. Matching this attachment requires two more oil circuits for the forklift;
Above listed models are common products of Handbarow, other models can also be provided for customer according to special working conditions. Please contact Handbarow sales representative.
