500kva silent generator 400kw

Specification of  500kva silent generator 400kw

Model: SFJ400

Rated Power: 400KW/500KVA

Standby Power: 440KW/550KVA

Rated speed: 1500 r/min

Noise Level: 75-78dB

Factor: COSΦ=0.8(lagging)

Phase/wire: 3 phase 4 wires

Rated Currency: 760 amps

Protection: Low oil-pressure, High water temperature, Over-speed, Over-current.

Engine of diesel generator set:

Brand: Cummins

Model: KTA19-G4

Origin: Manufactured by Chongqing Cummins Engine Co., Ltd

Cylinders: 6

Engine Power: 500kw/625kva

Start Model: DC24V electric start

Cylinders Layout: Line

Displacement: 18.9L

Speed-Governing: Electric

Steady Speed Droop: ≤1%

Alternator of diesel generator set:

Brand: Stamford

Model: HCI544D

Protection: IP23

Origin: Manufactured by Cummins Generator Technologies China

Rated Voltage: 220/380V(Adjustable)

Frequency regulation: ≤±0.5 %(stable)

Voltage Control: AVR

Controller of generator set:

Brand: DEEPSEA Smartgen

Optional accessories for diesel generator set:

1. ATS(Automatic Transfer switch), it can start generator set when the main power is off, once the main power comes back, the generator set will turn off automaticly.

And ATS have the function of AMF (automatic Main power failure)

2. MCCB(Molded case circuit breaker)

It can protect the loading machine and the diesel generator.

3. Battery charger (float charger)

When the generator hasn't been used for a long time, the batteries will be no power, in that way, you can't start the generator, but the battery charger can charge the batteries from the main power.

4. Extra daily fuel tank

It will be requested while the base fuel tank capacity is not enough for daily fuel consumption

5. Paralleling system

This system can make several generators work together and automatically distribute the load according to set.

6. Remote Control Panel

Which can control the generator by computer, if use a RS484 or RS232 digital cable to connect the generator to the computer.

7. Water separator (additional cooling system)

If the ambient temperature is too high, it will be harmful to the diesel generator. Fan and water cooling is not enough for radiate. The water separate system is much better for cooling, and the life of generator will be much longer.

 8. Spare Parts of Cummins engine

All the spare parts of each Cummins engine are supplied at very competitive price.
