Home > Products > Steel Gratings > Galvanized Catwalk Steel Grating
Galvanized Catwalk Steel Grating
- Tianjin
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | Hexing | |
| Model Number | HX-SG-41 | Material | Other, low-carbon steel,stainless steel,aluminum alloy etc |
Product Description
Steel grates
1.Material:
a.flat bar(bearing bar or load bar): low-carbon steel,stainless steel,aluminum alloy etc
b.cross bar:Q235 or other equivalent material
2.Surface Treatment:
Galvanized,painted,untreated,etc.
3.shape:
a. flat bar(bearing bar or load bar) surface shape: Serrated,Plain,I shape
b.cross bar:round shape and square twisted shape,etc.
4.Grating Dimension:
1) Flat bar(bearing bar or load bar)specifications (mm):
The specification of plain shape and serrated shape flat bar is 20*3 to 100*6;
The specification of I-shape is 25*5*3,32*5*3,38*5*3,40*5*3,50*5*3,50*7*4,55*7*4,60*7*4,65*7*4,70*7*4,75*7*4,etc.
2)Flat bar pitch (center to center):
12.5,15,30,34,40,60mm etc,also be according to client's requirement and 30,40, 60mm are recommended,
3)Cross bar pitch (center to center):
38,50,76,100,101.6mm etc,also be according to client's requirement and 50,100mm are recommended.
The sizes and dimension is not limited to above.
6.application:
Widely used in steel structure platforms,stair treads,sidewalks,drainages and well covers etc.We can manufacture standard steel grating and in customized shapes as your requirements.
7.our product:
8.Verified Information:
