LP-8 power amplifier specifications:

LP-8 power amplifier SPECIFICATIONS
Power per channel 8 ohms (1)	1200W
Power per channel 4 ohms (1)	1800W
Power bridged mono 8 ohms	3600W
Power bridged mono 4 ohms	4000W
Signal to noise ratio (20 Hz - 20 kHz)	105dB
Frequency response	15Hz~25KHz
Phase response	15hz to 25kHz
Intermodulation Distortion	0.06%
Slew rate	42V/us
Crosstalk	75dB
Input sensitivity 8 ohms	0.77/1.0/1.44V
Input sensitivity 4 ohms	0.77/1.0/1.44V
Voltage gain	75:1 +/-3%
Power supply (3)	Toroidal transformer
Damping factor @1kHz / 8 ohms	850
Damping factor @100Hz / 4 ohms	650
Input impedance	10kΩ un baianced -20kΩ baianced
Cooling	High/Low Automatism Cortrol
Input connectors, each channel	Balanced XLR and 1/4"(6.3mm)TRS
Output connectors, each channel	"ouch-proof"binding posts & SPEAKON
Grounding floating switch	Ground/Lift
Working mode (stereo/parallel/bridge)	stereo/parallel/bridge
Amplifier protections	DC Safeguard/out Overloading/Chancrois
	Sgartup/Boot-Strap Short Test
Active limiter (6)	commpressor
Active limiter ON/OFF switch	on/off
Rack size	3U
