[Hot Sale] Hytra HYT RD980 Original Cheap High Quality Professional Intercom in Cars Quality Choice

Specifications

[Hot Sale] High Quality Professional HYT   RD980 Two Way Radio

Specifications:

Basic information

Frequency range 400-470MHz 136-174MHz 350-400MHz

Channel number 16

Channel spacing of 25 / 20 / 12.5 kHz

A voltage of 13.6 + 15% V DC

Current consumption by current 1.2A

Emission current 12A

Frequency stability + 1ppm

Antenna impedance 50 ohm

Working cycle 100%

Size ( width * height * d ) 483 X 88 X 366 mm

The weight of 8.5 Kg

LCD display 220 * 176 pixels, 262K color

Transmission part

The output power of 5-50W ( adjustable )

FM modulation 11K than F3E @ 12.5 kHz

14K than F3E @ 20 kHz

16K than F3E @ 25 kHz

4FSK digital modulation mode 12.5kHz data only: 7K6 than FXD

The 12.5kHz data and voice: 7K6 than FXW

Transmitter spurious - 36dBm < 1GHz

- 30dBm > 1GHz

Modulation limiting + 2.5kHz @ 12.5 kHz

+ 4 kHz @ 20 kHz

+ 5.0kHz @ 25 kHz

FM 40dB @ 12.5 kHz noise

43dB @ 20 kHz

45dB @ 25 kHz

Adjacent channel power 60dB @ 12.5 kHz

70dB @ 20 / 25KHz

Audio response + 1 to - 3 dB

Audio distortion 3%

Digital speech coder AMBE + + / SELP

Receiving part

The sensitivity simulation of 0.3 V ( 12dB SINAD )

0.22 u V ( typical value ) ( 12dB SINAD )

0.4 ~ V ( 20dB SINAD )

Figure 0.3 u V / BER5%

Blocking 100dB

Adjacent channel selectivity 65dB @ 12.5 kHz / 75dB @ 20 / 25 kHz

Intermodulation 75dB @ 12.5 / 20 / 25 kHz

Spurious response inhibition of 85dB @ 12.5 / 20 / 25 kHz

The signal to noise ratio 40dB @ 12.5 kHz

43dB @ 20 kHz

45dB @ 25 kHz

Rated audio-frequency output power 0.5W

Rated 3% audio distortion

Audio response + 1 to - 3 dB

Conducted spurious - 57 dBm

Environmental index

Operating temperature range of - 30 DEG C to 60 C.

Storage temperature range of - 40 DEG C to 85 C
